Fashionable Wall Mounted Air Conditioner Series 9000BTU Low-Power Operation Inverter Frequency Air Conditioner Sp/J-Bp2a-26CH
Price:
280
MOQ:
100
Delivery Time:
Negotiable
Product Description
Fashionable Wall Mounted Air Conditioner Series 9000BTU Low-Power Operation Inverter Frequency Air Conditioner SP/J-BP2A-26CH
Product Description
| DC INVERTER | SP/J-BP2A-26CH | SP/J-BP2A-35CH | SP/J-BP2A-50CH | SP/J-BP2A-70CH | ||
| Rated Power supply | 1Ph / 220-240V/50Hz | 1Ph / 220-240V/50Hz | 1Ph / 220-240V/50Hz | 1Ph / 220-240V/50Hz | ||
| Workable Power supply | 1Ph / 150-260V/50Hz | 1Ph / 150-260V/50Hz | 1Ph / 150-260V/50Hz | 1Ph / 150-260V/50Hz | ||
| Cooling | Capacity (btu/h) | 9000 | 12000 | 18000 | 24000 | |
| Capacity (W) | 2500(150~3000)W | 3200(150~3600)W | 5100(1250-5910) | 7100(1830~7800) | ||
| Input (W) | 900(100~1200)W | 1180(75~1560)W | 1560(330-2340) | 2260(410~2830) | ||
| Rated current (A) | 4.0 (0.8~5.3)A | 5.3(0.5~6.9)A | 6.9(1.7~12.0) | 10.1(2.3~12.3) | ||
| Pdesign (W) | 2500 | 3200 | 5100 | 7100 | ||
| EER | 6.10 | 6.10 | 6.10 | 6.10 | ||
| Heating | Capacity (btu/h) | 9000 | 12000 | 18000 | 24000 | |
| Capacity (W) | 2800(150~3300)W | 3400(150~3800)W | 5100(1250-6070) | 7100(1850~7900) | ||
| Input (W) | 960(75~1260)W | 1160(75~1580)W | 1470(340-2520) | 2040(420~3000) | ||
| Rated current (A) | 4.3(0.5~5.6) | 5.2(0.5~7.0)A | 6.6(1.7~13.0) | 9.1(2.3~13.5) | ||
| Pdesign (W) | 2000 | 2100 | 3800 | 5000 | ||
| COP | 4.0 | 4.0 | 4.0 | 4.0 | ||
| Max. input consumption (W) | 1600 | 1720 | 2700 | 3200 | ||
| Max. current (A) | 8.00 | 9.00 | 13.00 | 15.80 | ||
| Compressor | Brand | GMCC | GMCC | GMCC | GMCC | |
| Type | Rotary | Rotary | Rotary | Rotary | ||
| Indoor unit | Indoor Coil | Fin material | Golden& hydrophilic& | Golden& hydrophilic& | Golden& hydrophilic& | Golden& hydrophilic& |
| Tube outside dia.and material | φ5mm, Inner Grooved | φ5mm, Inner Grooved | φ7mm, Inner Grooved | φ7mm, Inner Grooved | ||
| Indoor air flow (Turbo/Hi/Mi/Lo) (M3/h) | 500/450/370/320 | 550/500/450/370 | 850/750/650/580 | 1050/950/800/680 | ||
| Rated input Power(cooling/heating) (W) | 30 | 30 | 35 | 45 | ||
| Rated current (cooling/heating) (A) | 0.2 | 0.2 | 0.35 | 0.4 | ||
| Moisture Removal (KG/h) | 0.8 | 1.2 | 2 | 2.6 | ||
| Noise level(Turbo/Hi/Mi/Lo) (dB(A)) | 39/34/32/30 | 42/39/36/33 | 45/42/39/37 | 49/47/45/42 | ||
| Unit dimension (W*H*D) | 695*275*190 | 780*275*190 | 910*295*205 | 1075*330*240 | ||
| Packing (W*H*D) | 763*322*241 | 847*322*241 | 975*340*255 | 1146*412*318 | ||
| Net weight (KGs) | 6 | 7 | 11 | 15 | ||
| Gross weight (KGs) | 8 | 9 | 13 | 18 | ||
| Outdoor unit | Outdoor coil | Fin material | Golden& hydrophilic& | Golden& hydrophilic& | Golden& hydrophilic& | Golden& hydrophilic& |
| Tube outside dia.and material | φ7mm, Inner Grooved | φ7mm, Inner Grooved | φ7mm, Inner Grooved | φ7mm, Inner Grooved | ||
| Noise level (dB) | 50 | 52 | 55 | 59 | ||
| Unit dimension (W*D*H) (mm) | 710*295*495 | 710*295*495 | 780*350*600 | 850*385*700 | ||
| Packing (W*D*H) (mm) | 818*328*530 | 818*328*530 | 896*387*625 | 960*420*744 | ||
| Net weight (KGs) | 22 | 22 | 29 | 38 | ||
| Gross weight (KGs) | 25 | 25 | 33 | 42 | ||
| Refrigerant type | R32 | R32 | R32 | R32 | ||
| Refrigerant pipe | Liquid side (mm) | Φ6 | Φ6 | Φ6 | Φ6 | |
| Gas side (mm) | Φ9 | Φ9 | Φ12 | Φ12 | ||
| Max. refrigerant pipe length (m) | 10 | 10 | 10 | 15 | ||
| Max. difference in level (m) | 5 | 5 | 5 | 10 | ||
| Operation temperature range | -7ºC-43ºC | -7ºC-43ºC | -7ºC-43ºC | -7ºC-43ºC | ||
| Ambient temperature range | -15ºC-48ºC | -15ºC-48ºC | -15ºC-48ºC | -15ºC-48ºC | ||
| Application area (MM2) | 10~17 | 13~27 | 20~40 | 30~55 | ||
| Sets per 40ft HQ/20ft 40HQ/20 | 346/- | 334/143 | 230/99 | 146/- | ||
