Fashionable Wall Mounted Air Conditioner Series 18000BTU Low-Power Operation Fixed Frequency Air Conditioner Sp/J-50CH6
Price:
280
MOQ:
100
Delivery Time:
Negotiable
Product Description
Fashionable Wall Mounted Air Conditioner Series 18000BTU Low-Power Operation Fixed Frequency Air Conditioner SP/J-50CH6
Product Description
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
Product Description
| DC FIXED FREQUENCY | SP/J-26CH6 | SP/J-35CH6 | SP/J-50CH6 | SP/J-70CH6 | ||
| Rated Power supply | 1Ph / 220-240V/60Hz | 1Ph / 220-240V/60Hz | 1Ph / 220-240V/60Hz | 1Ph / 220-240V/60Hz | ||
| Workable Power supply | 1Ph / 185-260V/60Hz | 1Ph / 185-260V/60Hz | 1Ph / 185-260V/60Hz | 1Ph / 185-260V/60Hz | ||
| Cooling | Capacity (btu/h) | 9000 | 12000 | 18000 | 24000 | |
| Capacity (W) | 2500 | 3200 | 4800 | 6500 | ||
| Input (W) | 900 | 1220 | 1800 | 2300 | ||
| Rated current (A) | 4.10 | 5.70 | 8.10 | 10.70 | ||
| EER | 2.78 | 2.62 | 2.67 | 2.83 | ||
| Heating | Capacity (btu/h) | 9000 | 12000 | 18000 | 24000 | |
| Capacity (W) | 2500 | 3200 | 4800 | 6500 | ||
| Input (W) | 900 | 1160 | 1800 | 2300 | ||
| Rated current (A) | 4.10 | 5.40 | 8.10 | 10.70 | ||
| COP | 2.78 | 2.76 | 2.67 | 2.83 | ||
| Max. input consumption (W) | 1300 | 1750/1650 | 2500 | 3000 | ||
| Max. current (A) | 5.8 | 7.9/7.2 | 11.6 | 13.9 | ||
| Compressor | Type | Rotary | Rotary | Rotary | Rotary | |
| Brand | GREE,GMCC | GMCC | GMCC,ASF165N03UDTC | GMCC,PA205M2A-3ET | ||
| Indoor unit | Indoor Coil | Fin material | Golden& hydrophilic& | Golden& hydrophilic& | Golden& hydrophilic& | Golden& hydrophilic& |
| Tube outside dia.and material | φ7mm, Inner Grooved | φ7mm, Inner Grooved | φ7mm, Inner Grooved | φ7mm, Inner Grooved | ||
| Indoor air flow (Turbo/Hi/Mi/Lo) (M3/h) | 500/450/370/320 | 550/450/370/320 | 850/750/650/580 | 1050/950/800/680 | ||
| Rated input Power(cooling/heating) (W) | 30 | 30 | 80 | 45 | ||
| Rated current (cooling/heating) (A) | 0.2 | 0.2 | 0.35 | 0.4 | ||
| Moisture Removal (KG/h) | 0.8 | 0.8 | 2.6 | 2.6 | ||
| Noise level(Turbo/Hi/Mi/Lo) (dB(A)) | 39/34/32/30 | 40/35/32/30 | 45/42/39/37 | 49/47/45/42 | ||
| Unit dimension (W*H*D) | 695×275×190 | 780×275×190 | 910×295×205 | 1075×330×240 | ||
| Packing (W*H*D) | 763×322×241 | 847×322×241 | 975×340×255 | 1146×412×318 | ||
| Net weight (KGs) | 6 | 6.5 | 11 | 15 | ||
| Gross weight (KGs) | 8 | 8.5 | 13 | 18 | ||
| Outdoor unit | Outdoor coil | Fin material | Golden& hydrophilic& | Golden& hydrophilic& | Golden& hydrophilic& | Golden& hydrophilic& |
| Tube outside dia.and material | φ7mm, Inner Grooved | φ7mm, Inner Grooved | φ7mm, Inner Grooved | φ7mm, Inner Grooved | ||
| Noise level (dB) | 50 | 52 | 55 | 59 | ||
| Unit dimension (W*D*H) (mm) | 610×295×495 | 710×295×495 | 800(730)×305×550 | 850(780)×350×600 | ||
| Packing (W*D*H) (mm) | 704×324×530 | 818×328×530 | 835×340×580 | 896×387×625 | ||
| Net weight (KGs) | 21 | 23 | 29 | 42 | ||
| Gross weight (KGs) | 24 | 26 | 34 | 46 | ||
| Refrigerant type | R410A | R410A | R410A / 770g | R410A | ||
| Refrigerant pipe | Liquid side (mm) | Φ6 | Φ6 | Φ6 | Φ6 | |
| Gas side (mm) | Φ9 | Φ9 | Φ12 | Φ12 | ||
| Max. refrigerant pipe length (m) | 10 | 10 | 10 | 15 | ||
| Max. difference in level (m) | 5 | 5 | 5 | 10 | ||
| Operation temperature range | -7ºC-43ºC | -7ºC-43ºC | -7ºC-43ºC | -7ºC-43ºC | ||
| Ambient temperature range | -7ºC-48ºC | -7ºC-48ºC | -7ºC-48ºC | -7ºC-48ºC | ||
| Application area (MM2) | 10~17 | 13~27 | 20~40 | 30~55 | ||
| Sets per 40ft HQ/20ft 40HQ/20 | 360/164 | 334/140 | 280/133 | 186/78 | ||
