Fashionable Wall Mounted Air Conditioner Series 12000BTU Low-Power Operation Fixed Frequency Air Conditioner Sp/J-35c6
Price:
280
MOQ:
100
Delivery Time:
Negotiable
Product Description
Fashionable Wall Mounted Air Conditioner Series 12000BTU Low-Power Operation Fixed Frequency Air Conditioner SP/J-35C6
Product Description
| DC FIXED FREQUENCY | SP/J-26C6 | SP/J-35C6 | SP/J-50C6 | SP/J-70C6 | ||
|---|---|---|---|---|---|---|
| Rated Power supply | 1Ph / 220-240V/60Hz | 1Ph / 220-240V/60Hz | 1Ph / 220-240V/60Hz | 1Ph / 220-240V/60Hz | ||
| Workable Power supply | 1Ph / 185-260V/60Hz | 1Ph / 185-260V/60Hz | 1Ph / 185-260V/60Hz | 1Ph / 185-260V/60Hz | ||
| Cooling | Capacity (btu/h) | 9000 | 12000 | 18000 | 24000 | |
| Capacity (W) | 2500 | 3200 | 4800 | 6500 | ||
| Input (W) | 900 | 1220 | 1800 | 2300 | ||
| Rated current (A) | 4.10 | 5.70 | 8.10 | 10.70 | ||
| EER | 2.78 | 2.62 | 2.67 | 2.83 | ||
| Heating | Capacity (btu/h) | / | / | / | / | |
| Capacity (W) | / | / | / | / | ||
| Input (W) | / | / | / | / | ||
| Rated current (A) | / | / | / | / | ||
| COP | / | / | / | / | ||
| Max. input consumption (W) | 1300 | 1750 | 2600 | 3000 | ||
| Max. current (A) | 5.8 | 7.9 | 12.40 | 13.9 | ||
| Compressor | Type | Rotary | Rotary | Rotary | Rotary | |
| Brand | GREE,GMCC | GREE | GMCC,ASF165N03UDTC | GMCC,PA205M2A-3ET | ||
| Indoor unit | Indoor Coil | Fin material | Golden& hydrophilic& | Golden& hydrophilic& | Golden& hydrophilic& | Golden& hydrophilic& |
| Tube outside dia.and material | φ7mm, Inner Grooved | φ7mm, Inner Grooved | φ7mm, Inner Grooved | φ7mm, Inner Grooved | ||
| Indoor air flow (Turbo/Hi/Mi/Lo) (M3/h) | 500/450/370/320 | 550/450/370/320 | 850/750/650/580 | 1050/950/800/680 | ||
| Rated input Power(cooling/heating) (W) | 30 | 30 | 80 | 45 | ||
| Rated current (cooling/heating) (A) | 0.2 | 0.2 | 0.35 | 0.4 | ||
| Moisture Removal (KG/h) | 0.8 | 0.8 | 2.6 | 2.6 | ||
| Noise level(Turbo/Hi/Mi/Lo) (dB(A)) | 39/34/32/30 | 40/35/32/30 | 45/42/39/37 | 49/47/45/42 | ||
| Unit dimension (W*H*D) | 695*275*190 | 780*275*190 | 910*295*205 | 1075*330*240 | ||
| Packing (W*H*D) | 763*322*241 | 847*322*241 | 975*340*255 | 1146*412*318 | ||
| Net weight (KGs) | 6 | 6.5 | 11 | 15 | ||
| Gross weight (KGs) | 8 | 8.5 | 13 | 18 | ||
| Outdoor unit | Outdoor coil | Fin material | Golden& hydrophilic& | Golden& hydrophilic& | Golden& hydrophilic& | Golden& hydrophilic& |
| Tube outside dia.and material | φ5mm, Inner Grooved | φ5mm, Inner Grooved | φ5mm, Inner Grooved | φ7mm, Inner Grooved | ||
| Noise level (dB) | 50 | 52 | 53 | 59 | ||
| Unit dimension (W*D*H) (mm) | 610*295*495 | 710*295*495 | 800(730)*305*550 | 850(780)*350*600 | ||
| Packing (W*D*H) (mm) | 704*324*530 | 818*328*530 | 835*340*580 | 896*387*625 | ||
| Net weight (KGs) | 20 | 21 | 29 | 37 | ||
| Gross weight (KGs) | 23 | 24 | 34 | 41 | ||
| Refrigerant type | R410A | R410A | R410A | R410A | ||
| Refrigerant pipe | Liquid side (mm) | Φ6 | Φ6 | Φ6 | Φ6 | |
| Gas side (mm) | Φ9 | Φ9 | Φ12 | Φ12 | ||
| Max. refrigerant pipe length (m) | 10 | 10 | 10 | 15 | ||
| Max. difference in level (m) | 5 | 5 | 5 | 10 | ||
| Operation temperature range | 16ºC-43ºC | 16ºC-43ºC | 16ºC-43ºC | 16ºC-43ºC | ||
| Ambient temperature range | 16ºC-48ºC | 16ºC-48ºC | 16ºC-48ºC | 16ºC-48ºC | ||
| Application area (MM2) | 10~17 | 13~27 | 20~40 | 30~55 | ||
| Sets per 40ft HQ/20ft 40HQ/20 | 360/164 | 334/140 | 280/133 | 186/78 | ||
