P1.25 DC5V Small Pixel Pitch Led Screen Panel Display 4k Video Wall
Small Pixel Pitch Led Display HD High Resolution P1.25 4K High Quality Display
Product Introduction
Our Small Pixel Pitch LED Display delivers clear images, vivid colors, and fine details. With seamless splicing and flexible installation options, it is ideal for indoor applications requiring high-resolution display performance.
Product Specifications
| Type | P1.25 |
| Pitch | 1.25mm |
| Series | Flexible 320*160mm |
| Cabinet Type | Customized |
| Access / Maintenance | Front Maintenance |
| LED Model & Type | 1010 |
| LED Make | Rayshine |
| Refresh | 3840Hz adjustable |
| Brightness | 600-800nits |
| Contrast | 5000:1 |
| Viewing Angle | H 160°,V 160° |
| Scan | 64s |
| Density(dot/m²) | 640000 |
| Module Pixels (L*H) | 256*128 |
| Module Size (L*H)mm | 320*160mm |
| Module Depth (mm) | 7mm |
| Max Power (watts / m²) | 520 |
| Avg Power (watts/m²) | 195 |
| Module Weight (kg/pcs) | 0.25kg |
| Certification | 3C CE ROHS |
| Ingress Protection (IP) | IP30 |
| Grayscale | ≥14bit |
| Control mode | Synchronous control or Asynchronous control |
| Operation Temperature | - 20 ℃ ～ + 45 ℃ |
| Operation Humidity | 10 % ～ 95 % |
| Life Span | 100000h |
| Compatible Function | Double power supply&receive card (One for use,one for back up) |
Product Advantages
1.Ultra high definition
It delivers a truly amazing picture with extraordinary pixels producing an image that is HD quality in an LED screen
2.High strength Aluminum alloy material
The integral die-casting aluminum molding workmanship has provided with excellent flatness of the cabinet
3.Front serviceable led screen for better experience
The front serviceable ultra HD led screen cabinet has fully described the strength of its light weight,met the needs of small space or where the needs of the cabinet thickness is needed, enhanced the vision of the space as well as its visionary effect.
it allows for easy maintenance, saving time and labor site.
Packaging & Shipping
Packing: Anti-shaking wooden cabinet / Air flight case/strong carton
Shipping port: Shenzhen , China
Shipping way:Air ; Express ; Ocean ; Land Transportation
Delivery time: 15 - 18 working days after confirm receipt payment in advance
Long working life: In the Maintenance period , free of all maintenance charge
After maintenance period only charge the material costs fees
Product Applications
- Conference Rooms: Presentations and video meetings.
- Control Rooms: Monitoring, data, and command centers.
- TV Studios: Broadcast backgrounds and video production.
- Museums & Exhibition Halls: Digital exhibits and visual presentations.
- Shopping Malls: Advertising and brand promotion.
- Corporate Showrooms: Product displays and company presentations.
