Product Description

500x500mm 1000nits Modular Led Display Panels Wedding Led Screen Rental




Features


1. Easy to calculate the area of LED screen because it is consist of 500 * 500mm/500mm*1000mm cabinet;


2. 16 bit color, 65536 gray scale, refresh rate over 3840HZ so the video or images on the LED screen

are very vivid and fresh, people who see it will get shocked by this amazing viewing experience;

3. The appearance is very elegant, it looks very high end and quality is very stable;

4. It is die - casting aluminum cabinet , very strong and precision is very high ,
tolerance can be

controlled in 0.1mm so the surface is very smooth , almost no gap between cabinets;

5. The side locks is spring locks, this is unique among all die-casting aluminum
cabinets , especially

popular in European market and North American market.




Technical parameters


Type P3.91
 Pitch  3.91
Series 500*1000mm Indoor Rental Series
Cabinet Type Die-casting Aluminum
Access / Maintenance Front/Rear
LED Model & Type SMD2121
LED Make Rayshine
Driving IC Model Make FM6373/ICND1065S/DP3364S
 Refresh  3840Hz adjustable
Brightness 600-800nits
Contrast 5000:1
Viewing Angle H 160°, V 160°
Control System NovaStar
Max Wattage (Watts) 160
Avg Wattage (Watts) 48
Scan 1/16
Density(dot/m²) 4096
Module Pixels (L*H) 64*64
Module Size (L*H)mm 250*250mm
Cabinet Resolution (dot) 32768
Cabinet Size (L*H)mm 500*1000mm
Cabinet Depth (mm) 86mm
Single Cabinet weight (kg) 12KG
Max Power (watts / m²) 320
Avg Power (watts/m²) 96
Weight (kg/m²) 24
Certification 3C CE ROHS
Ingress Protection (IP) IP30
Grayscale 14-16bit+
Control mode Synchronous control or Asynchronous control
Operation Temperature - 20 ℃ ~ + 45 ℃
Operation Humidity 10 % ~ 95 %
Life Span 100000h
Compatible Function Double power supply&receive card (One for use,one for back up)





FAQ

1 : What is the warranty of your led display ?
A : We offer 5 years warranty , and more than 100000 hours screen life span .

2 : what is your payment term ?How long it takes to delivery ?
A : We usually accapt the T / T or L / C both of them will at least 30 % deposit in advance , and the rest

of 70 % will paid before delivery .The lead time is usually 20 day .

3 : How can you ensure the led display product quality ?
A : Before shippment , all the screens have aging test , and then we also have waterproof test and shake

test , ensure products can transportation safety and normal use .

4 : What is your pre - sale and post - sale service ?
A : For pre - sale service , we have professional sales team and technical team ,who are willing to answer

your question within 24 hours .
For post - sale service , we will instruct you how toinstallation , how to use , how to change the broken

moudles , and we can also send the technicals to your country , in general , our led display will not have

a big problem , you can rest assured to buy .





Services

1 . Your inquiry related to our products or price will be replied in 24hrs .
2 . OEM&ODM,any your customized lightings we can help you to design and put into product .
3 . Distributoership are offered for your unique design and some our current models .
4 . Protection of your sales area,ideas of design and all your private information .
5 . Best cost performance and perfect service before and after sales .
