20KHZ Industrial Metal Melting Furnace
15-160KW Stainless Stel Industrial Metal Melting Furnace Medium Frequency
1. Company Introduction
The medium frequency power supply can be used in heat treatment
processes such as melting, forging, welding, quenching, heat treatment,
heat foriming, heat correction, and pipe heating. The medium frequency
power supply ranges from 15-250KW. The industrial metal melting furnace
with medium frequency power supply has a fast melting speed when it comes
to melt stainless steel, copper, aluminum, industrial silicon, etc. It has a low
melting loss, saves energy consumption, and reduces the production cost.
The titlting type medium frequency industrial metal melting furnace is of a small
and compact design.
2.Technical Parameters of industrial metal melting furnace
| Working Power | 15-160KW |
| Output oscillation frequency | 1-20KHZ |
| Capacity | 3-250KG stainless steel |
| Cooling type | Water cooling |
3.Model Table
| No. | Melting capacity of Stainless | Input power | Overall Dimension (mm, L,W,H) |
| 1 | 10KG |
15KW
|
Furnace body:800*550*750mm Power cabinet:530*290*520mm Capacitor cabinet :500*230*460mm |
| 2 | 20KG |
25KW
|
Furnace body:800*550*750mm power cabinet::530*290*520mm capacitor cabinet:500*230*460mm |
| 3 | 30KG |
35KW
|
Furnace body:830*560*920mm power cabinet:630*340*540mm capacitor cabinet:500*230*460mm |
| 4 | 50KG |
45KW
|
Furnace body:890*620*1020mm power cabinet:700*350*620mm capacitor cabinet:500*230*460mm |
| 5 | 100KG |
70KW
|
Furnace body:940*650*1100mm power cabinet:700*350*620mm capacitor cabinet:550*400*510mm |
| 6 | 120KG |
90KW
|
Furnace body:940*650*1100mm power cabinet:820*420*890mm capacitor cabinet:550*400*510mm |
| 7 | 150KG |
110KW
|
Furnace body:1050*790*1200mm power cabinet:820*420*890mm capacitor cabinet:550*400*510mm |
| 8 | 250KG |
160KW
|
Furnace body:1050*790*1200mm power cabinet:750*500*960mm capacitor cabinet:550*400*510mm |
4.Main Features
4.1 The industrial metal melting furnace adopts IGBT power device and unique frequency
conversion technology to operate stably and provide higher reliability and durability. It has
the function of constant current and constant power control, which greatly optimizes the metal
heating process, realizes efficient and fast heating, and gives full play to the advantages of
the product. Under the same conditions, it has twice the power saving than the traditional SCR
medium frequency.
4.2 The industrial metal melting furnace has alarm function and fault detection function,
such as fault state protection and display including overcurrent, overvoltage and water shortage, etc.
