High Quality F205 Flange Units Square Chrome Pedestal Block Bearing UCF205-16
High Quality Square Flange Units Bearing F205 Pedestal Bearing UCF205-16
Description: of Flange Units
The flange bearing UCF208 is suitable for very high radial loads and for installation in various applications. It is particularly
robust with its gray cast iron housing.
* Designed for high temperatures and speeds
* Accommodate relatively heavy loads
* Cost-effective
Specifications: of Flange Units
|
Product Name |
High quality Flange Units
|
|
Brand
|
Deep dream&OEM
|
| Bearing Inner Diameter Metric/Inch | 25mm/1 in |
|
Model No
|
UCF205 |
|
Material
|
Chrome Steel, Bearing steel; GCr15; carbon steel, brass
|
|
Precision
|
P0
|
|
Clearance
|
C0, C2, C3, C4
|
|
Usage
|
Used for Mining, metallurgy, agriculture, chemical industry, textile, printing and dyeing, conveying machinery.
|
| Unit No. | Dimensions(mm) | Bolt Size | Bearing No. | Housing No | ||||||||||
| d | a | e | i | g | l | s | z | t | B | n | ||||
| UCF201 | 12 | 86 | 64 | 15 | 12 | 26 | 12 | 33 | 37.5 | 31 | 12.7 | M10 | UC201 | F204 |
| UCF202 | 15 | 86 | 64 | 15 | 12 | 26 | 12 | 33 | 37.5 | 31 | 12.7 | M10 | UC202 | F204 |
| UCF203 | 17 | 86 | 64 | 15 | 12 | 26 | 12 | 33 | 37.5 | 31 | 12.7 | M10 | UC203 | F204 |
| UCF204 | 20 | 86 | 64 | 15 | 12 | 26 | 12 | 33 | 37.5 | 34 | 14.3 | M10 | UC204 | F204 |
| UCF205 | 25 | 95 | 70 | 16 | 14 | 27 | 12 | 36 | 40 | 34 | 14.3 | M10 | UC205 | F205 |
| UCF206 | 30 | 108 | 83 | 18 | 14 | 31 | 12 | 40 | 44.5 | 38 | 15.9 | M10 | UC206 | F206 |
| UCF207 | 35 | 117 | 92 | 19 | 16 | 34 | 14 | 44 | 48.5 | 43 | 17.5 | M12 | UC207 | F207 |
| UCF208 | 40 | 130 | 102 | 21 | 16 | 36 | 16 | 51 | 55.5 | 49 | 19 | M14 | UC208 | F208 |
| UCF209 | 45 | 137 | 105 | 22 | 18 | 38 | 16 | 52 | 56.5 | 49 | 19 | M14 | UC209 | F209 |
| UCF210 | 50 | 143 | 111 | 22 | 18 | 40 | 16 | 55 | 59.5 | 52 | 19 | M16 | UC210 | F210 |
| UCF211 | 55 | 162 | 130 | 25 | 20 | 43 | 19 | 58 | 63 | 56 | 22.2 | M16 | UC211 | F211 |
| UCF212 | 60 | 175 | 143 | 29 | 20 | 48 | 19 | 69 | 73.5 | 65 | 25.4 | M16 | UC212 | F212 |
| UCF213 | 65 | 187 | 149 | 30 | 22 | 50 | 19 | 70 | 74.5 | 65 | 25.4 | M16 | UC213 | F213 |
| UCF214 | 70 | 193 | 152 | 31 | 22 | 54 | 19 | 75 | 81.5 | 75 | 30.2 | M16 | UC214 | F214 |
| UCF215 | 75 | 200 | 159 | 34 | 22 | 56 | 19 | 79 | 83.5 | 78 | 33.3 | M16 | UC215 | F215 |
| UCF216 | 80 | 208 | 165 | 34 | 22 | 58 | 23 | 83 | 88.5 | 83 | 33.3 | M20 | UC216 | F216 |
| UCF217 | 85 | 220 | 175 | 36 | 24 | 63 | 23 | 88 | 92.6 | 86 | 34.1 | M20 | UC217 | F217 |
| UCF218 | 90 | 235 | 187 | 40 | 24 | 68 | 23 | 96 | 102 | 96 | 39.7 | M20 | UC218 | F218 |
1. High speed, High Precision, Low Noise, Long Service Life
2. Widely used
3. Large Inventories
4. High Quality and Competitive Prices
5. Various Brands
6. OEM is supported
Applications:
Papermaking machinery, speed reducer, railway vehicle axle, gear box bearing, rolling mill rolling mill rolls, crusher, vibrating screen, printing machinery, woodworking machinery, all kinds of industry.
FAQ
1. who are we?
We are based in Shaanxi, China, start from 2019,sell to North America(17.00%),Eastern Asia(15.00%),Domestic Market(12.00%),Eastern Europe(10.00%),Western Europe(10.00%),South Asia(5.00%),Southeast Asia(5.00%),South America(5.00%),Northern Europe(5.00%),Oceania(5.00%),Mid East(4.00%),Southern Europe(3.00%),Africa(2.00%),Central America(2.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
deep groove ball bearing,needle rollerbearing,bearings, pillow block bearing,tapered roller bearing
4. why should you buy from us not from other suppliers?
Our company is located in Xi'An, China. With advanced science and technology R&D team, strong marketing and financial support, sound after-sales service, professional engineers, we will supply you goods with high quality and good service.
