Precision Seamless Steel Pipe ASTM A106 Gr B SAE 1020 1045 ST52 Cold Drawn
ASTM A106 Gr. B/SAE 1020 1045/St52 Cold Drawn Precision Seamless Steel Pipe
1. Usage: Pipeline Transport, Boiler Pipe, Hydraulic/Automobile Pipe, Oil/Gas Drilling, Food/Beverage/Dairy Products, Machinery Industry, Chemical Industry, Mining, Construction & Decoration, Special Purpose
2. Commodity: Cold Drawn Precision Seamless Steel Pipe
3. Size range: Inside diameter: 25mm -500mm; Wall thickness: 2-50mm
4. Available steel grade:
| SAE/AISI: | SAE1020, SAE1026, SAE1045, SAE4130, SAE4140 |
| DIN: | ST52, ST52.3, ST52.4 |
| EN: | E355, C45E, 25CrMo4, 42CrMo4, CK45, S45C, E410, E470 |
| GB: | 20#, 45#, 16Mn, Q345B, Q345C, Q345D, Q345E, 25Mn, 27SiMn, |
5. Manufacture method: Cold rolled, hydraulic cold drawn, hot rolled+deep hole boring
6. Delivery condition:
| BK | BKW | BKS | GBK | NBK | Q+T |
| +C | +LC | +SR | +A | +N | |
| Cold rolled | Cold drawn | Stress relieved | Annealed | Normalized | Quenched+Tempered |
7. Bore treatment: Honing, skiving&roller burnishing
8. Bore roughness control: Ra0.25um max or Ra0, 35um max for honed tubes, Ra0.25um max for skived&roller burnished tubes.
9. End finish: Plain ends with square cuts, free of burrs for honed tubes. Little bevelled ends for skived&roller burnished tubes.
10. Standard export packing: In bundles tied with steel strips. Internal & external oil coating. Plastic caps on both ends. External packing by PVC bags and knit bags.
11. Customized packing and marking can be provided upon request.
12. H8 tolerance:
| ID range | Tolerance | ID range | Tolerance |
| 18< d ≤30 | +0/+0.033 | 180< d ≤250 | +0/+0.072 |
| 30< d ≤50 | +0/+0.039 | 250< d ≤300 | +0/+0.081 |
| 50< d ≤80 | +0/+0.046 | 300< d ≤315 | +0/+0.081 |
| 80< d ≤120 | +0/+0.054 | 315< d ≤400 | +0/+0.089 |
| 120< d ≤180 | +0/+0.063 | 400< d ≤500 | +0/+0.097 |
13. Difference between honed tube and skived & roller burnished tube: In hydraulic cylinder industry, there are 2 solutions for bore treatment: Honing, and skiving&roller burnishing. Honing or skiving&roller burnishing leads to different internal surface image, but both ensure good roughness.
FAQ:
Q:Can you send samples?
A:Of course, we can send samples to all parts of the world.
A:Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao ports, you can choose other ports according to your needs.
Q:What are the certifications for your products?
A:We have ISO 9001, SGS, EWC and other certifications.
Q:How long does your delivery time take?
A:In general, our delivery time is within 7-15 days, and may be delayed if the demand is extremely large or special circumstances occur.
Q:Can I go to your factory to visit?
A:Of course, we welcome customers from all over the world to visit our factory.
Q:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.
Q:How to pack the products?
A:The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation wooden pallet. It caneffectively protect products from corrosion during ocean transportation.Send your message to this supplier
