Q195 6m Length ERW Hot Rolled Metal Steel Round Tube Black Iron Carbon Steel Pipe
Q195 6m Length ERW Hot Rolled Metal Steel Round Tube Black Iron Carbon Steel Pipe
Product Description
Outer Diameter: 1/8"-36"(10.3mm-914.4mm)
Wall Thickness: 1.0mm-20mm
Length: Random Length,SRL,DRL(4-14M)
Steel Grade:
A53 Gr. A, Gr B, A106 GR.A GR.B A333 GR1 GR3 GR6
End:pland ends beveled ends
Surface: Bare, Black,Lightly oiled, Hot dip galvanized,, Varnish coating/Anti rust oil, Protective Coatings, 3PE
| ASTM A53 /A106 Chemical Components and Machanical Property | |||||||||||||
| Standard | Steel Grade | Chemical Components | Machanical Property | ||||||||||
| C | Mn | P | S | Cu | Ni | Cr | Mo | V | Tensile Strength (Mpa) | Yield Strength(Mpa) | Elongation (Mpa) | ||
| ASTM A53 | A | ≤0.25 | ≤0.95 | ≤0.05 | ≤0.045 | ≤0.40 | ≤0.40 | ≤0.40 | ≤0.15 | ≤0.08 | ≥330 | ≥205 | ≥29.5 |
| B | ≤0.30 | ≤1.20 | ≤0.05 | ≤0.045 | ≤0.40 | ≤0.40 | ≤0.40 | ≤0.15 | ≤0.08 | ≥415 | ≥240 | ≥29.5 | |
| Standard | Steel Grade | Chemical Components | Machanical Property | ||||||||||
| C | Si | Mn | P | S | Cu ,Ni | Cr | Mo | V | Tensile Strength (Mpa) | Yield Strength(Mpa) | Elongation (Mpa) | ||
| ASTM A106 | B | ≤0.30 | ≥0.10 | 0.29-1.06 | ≤0.035 | ≤0.035 | ≤0.40 | ≤0.40 | ≤0.15 | ≤0.08 | ≥415 | ≥240 | ≥30 |
| C | ≤0.35 | ≥0.10 | 0.29-1.06 | ≤0.035 | ≤0.035 | ≤0.40 | ≤0.40 | ≤0.15 | ≤0.08 | ≥485 | ≥275 | ≥30 | |
Spiral welded pipe: low carbon carbon structural steel or low alloy structural steel strip according to a certain Angle of the spiral line (called forming Angle) rolled into the tube blank, and then welded pipe seam made, it can use a narrower strip to produce large diameter steel pipe. The specifications are denoted by outer diameter * wall thickness. The welded pipe shall ensure that the hydrostatic test, tensile strength and cold bending performance of the weld shall meet the requirements.
Industrial TV internal inspection equipment: inspection of internal weld appearance quality.
Magnetic particle flaw detector: inspection of large diameter steel pipe near surface defects.
Ultrasonic automatic continuous flaw detector: to test transverse and longitudinal defects of full length welds of spiral steel pipes.
Ultrasonic manual flaw detector: reinspection of defect of large diameter steel pipe, inspection of repair welding seam and weld quality after water pressure.
X-ray automatic flaw detection machine and industrial TELEVISION imaging equipment: to test the internal quality of the full length welding seam of spiral steel pipe, sensitivity is not less than 4%.
X-ray film equipment: the original weld and repair weld inspection, sensitivity is not less than 2%.
2200 tons hydraulic press and microcomputer automatic recording system: test the bearing quality of each large diameter steel pipe.
