Military Infrared Thermal Imaging Cooling With GPS, Electronic Compass, Laser Ranging
Price:
Negotiable
MOQ:
10
Delivery Time:
3~7
Brand:
OEM, ODM All Available
Product Description
Military Infrared Thermal Imaging Cooling With GPS, Electronic Compass, Laser Ranging
Parameter:
| Specification of cooled thermal imaging binocular | |
| Sensor type | cooled FPA |
| Resolution | 320*256 |
| Wavelength | 3-5μm |
| Pixel pitch | 30μm |
| NETD | 25MK./@25℃ |
| MRTD | ≤0.18K |
| Frame rate | 50HZ |
| Cool down type | <6min |
| Lens | f=20-200mm F#4.0 |
| Focus | Auto/manual |
| FOV | 2.75°x2.2°~18.3°x14.7° |
| Electronic zoom | 1x~4x |
| Image control | White/black polarity;auto,manual gain, |
| Day/Night imaging | |
| Sensor type | 1/2' Low luminance camera |
| Resolution | 720TVL |
| Frame rate | 25HZ |
| Lens | f=50mm |
| Focus | f=50mm |
| Working luminance | 0.001lux |
| Display | |
| Display type | OLED |
| Resolution | 1024x768 |
| Reticles luminance | Customized |
| GPS | |
| GPS | GPS,SNMS |
| GPS accuracy | ≤10m. |
| Target geolocation | opitions |
| DMC | |
| Type | Digital Compass |
| Accuracy | ≤1°(Heading) |
| LRF | |
| Type | 1.54μm |
| Eye safe | Eye safe Class1 |
| Min.distance | 100m |
| Max.distance | 5Km(atmosphere visibility>3.5km) |
| Accuracy | ≤2m |
| Frequency | 20ppm |
| System | |
| Standby | Yes |
| Video out | BNC PAL |
| Recoding memory | 32G |
| Working temp. | -30℃/55℃ |
| Waterproof | IP67 |
| Drop test | 1.5m |
| interface | USB2.0 |
| Power | +12v~+16v |
| Working time/cycle | 4h(20℃) |
| Battery type | Li-ion |
| External power | +24v |
| Tripod connection | 1/4‘ |
| Included cables | Batteries,1charger,AC/DC adaptor,connection cable,hard case |
Features:
1.High resolution thermal imager,high resolution visual camera,work all day,see through glare;
2.GPS,electrical compass,eye-safe laser range finder
3.The output imager can be displayed on its color OLED display and alternatively on a control&display units connected to a host machine which makes it suitable for comples maneuvers
