CU DHP Soft Freezer Copper Pipe , Copper Tubing For Petroleum Industry
C12000 Condenser Tube Widely Used In Petroleum Industry And Petrochemical Industry
Product Description
Copper condenser tube,designed for the condenser, the sharp ridges on the radial and axial outside finned section of the tube destroy the surface tension of gas. The Process of Copper Condenser Tube is Extruded processes (Rolling).Copper Condenser Tube will pass 100% Eddy Current Testing, 100% hydraulic Testing.OEM opper condenser tubeis available according to drawings and/or samples.
Application
Copper condenser tube suitable for central air-conditioner centrifuge, water-cooled screw chilled water units, the shell heat exchanger, heat exchanger with phase transition.Copper condenser tubes are widely used in petroleum industry, petrochemical industry, metallurgical industry, power industry, maritime,home appliances such as refrigerator and air-condition, automobile industry etc.
Packing of copper condenser tube Outside: Plywood sea-worthy case or pallet.
| Copper Condenser Tube |
| Item | Light tube | Wing fragment | |||||||
| O.D. | O.D. | Wall Thickness | minimum Wall Thickness | Ridge Height | Nominal outside surface area | actualoutside surface area | Nominal inside surface area | Nominal inside surface area | |
| mm | mm | mm | mm | mm | ㎡/m | ㎡/m | ㎡/m | ㎡/m | |
| 1 | 12.7 | 12.65 | 0.6 | 0.5 | 0.2 | 0.0399 | 0.1101 | 0.0348 | 0.0433 |
