P2.9 P3.9 P4.8 Church Stage Backdrop Outdoor Rental Led Screen King Visionled
Outdoor Indoor HD Stage Background Slim P3.9 Good Price Rental LED Video Wall Panel Screen
LED Display Features:
1,Indoor stage, TV studio, concert, theme park ,Stage Performance ,Live Events ,clubs, presentation ,concerts, festivals, , halls, shop windows or exhibitions ,conference ,Freestanding stage backdrops and other places for advertising and entertaining purposes.
2. stage shows ,big concert, wedding background , media Facade , Video Productions.
| Module Number | PH2.604 | PH2.976 | PH3.91 | PH4.81 |
| Pixel Pitch | 2.604mm | 2.976mm | 3.91mm | 4.81mm |
| Physical Density | 147456 pixels/m2 | 112896 pixels/m2 | 65536 pixels/m2 | 43264 pixels/m2 |
| Led Arrangement | 3 in 1SMD | 3 in 1 SMD | 3 in 1SMD | 3 in 1 SMD |
| Module Resolution | 96*96 pixels | 84*84 pixels | 64*64 pixels | 52*52 pixels |
| Module Dimensions | 250*250 mm | 250*250mm | 250*250 mm | 250*250mm |
| Cabinet Resolution | 192*192 pixels | 168*168 pixel | 128*128 pixels | 104*104 pixel |
| Cabinet Dimensions | 500*500 mm | 500*500 mm | 500*500 mm | 500*500 mm |
| Cabinet Weight | 7.5kg | 7.5kg | 7.5kg | 7.5kg |
| Brightness | ≥5000 nits | ≥5000 nits | ≥5000 nits | ≥5000 nits |
| Max Power Consumption | 180w/panel | 180w/panel | 180w/panel | 132w/panel |
| Ave Power Consumption | 60w/panel | 60w/panel | 60w/panel | 44w/panel |
| Viewing Angle | 160°(W) 160°(H) | 160°(W) 160°(H) | 160°(W) 160°(H) | 160°(W) 160°(H) |
| Operating Power source | 110-240V AC 50-60Hz | 110-240V AC 50-60Hz | 110-240V AC 50-60Hz | 110-240V AC 50-60Hz |
| Operating Temperature | -20℃～+50℃ | -20℃～+50℃ | -20℃～+50℃ | -20℃～+50℃ |
| Refresh Rate | 3840Hz | 3840Hz | 3840Hz | 3840Hz |
| IP Rating | IP65 | IP65 | IP65 | IP65 |
| Signal Input Source | Composite, S-video, Component, HDMI, SDI, HD, VGA, DVI | Composite, S-video, Component, HDMI, SDI, HD, VGA, DVI | Composite, S-video, Component, HDMI, SDI, HD, VGA, DVI | Composite, S-video, Component, HDMI, SDI, HD, VGA, DVI |
| Verification | ETL, FCC, CCC, RoHS,CE | ETL, FCC, CCC, RoHS,CE | ETL, FCC, CCC, RoHS,CE | ETL, FCC, CCC, RoHS,CE |
before. Rotational control, more accurate, easy to use and quickly adjust curve degree.
Shenzhen King Visionled Optoelectronics Co.Ltd is a manufacturer which have lead-edge technologies in solving problems of led field.Jinhe was established in 2006 Shenzhen, with a plant area of 10,000 square meters, stuffs is 300 members,.At the end of 2012,the producing capability was reached up to 10000sq.m per month.It become the leading manufacturer in the LED industry soon.It's one of the fastest growing companies in China.
Stable-quality is the foundation that makes us survive,high quality products and good sales performance is the supporter that drives us moving,innovation and invention is the guarantee that makes the product competitively,talent is a big power that pushes the company become stronger and bigger.Widely using automatic machine production line,it is one of the companies which has the most automated stage of production and have completely equipment and facilities.Our products have passed International Environmental Certification of ROHS,CE,and CCC.That makes the production internationalized.Our products have been sold to more than 60 countries and areas in the world.
Q1: What's the pixel pitch for Indoor LED Display Screen ?
A1: 1.2mm/1.6mm/1.9mm/2.5mm/2.9mm/3mm/3.75mm/4mm/5mm/6mm/4.8mm/5.95mm
Q2: Where is indoor LED diplay screen used for?
A2: Indoor rental use. Widely used for backdrop of staging event, rental business, liveshow, concert, etc. Indoor fixed installation use.
Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Novastar controlling system.
