Customized Stage Background LED Display Indoor / Outdoor P2.6 P2.9 P3.91 P4.81
Rental led screen series
p2.6 / p2.9/ p3.9/p4.8 indoor and outdoor led display, 3840 high refresh 500*500mm cabinets /500*1000mm cabinet,indoor brightness
≥1000nits ,outdoor brightness ≥5000nits,
Novastar control system, with power connector and signal connector , flight case available too , welcome to inquiry.
| Model | P2.6-IN | P2.9-IN | P3.9-IN | P3.9-OD | P4.8-OD |
| Pixel Pitch | 2.6 | 2.9 | 3.9 | 3.91 | 4.81 |
| Pixel Density(dot/m2) | 147,456 | 112896 | 65536 | 65536 | 43264 |
| LED Type | SMD2121 | SMD2121 | SMD2121 | SMD1921 | SMD1921 |
| Module Size(mm*mm) | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 |
| Cabinet Size(mm*mm*mm) | 500*500*73 | 500*500*73 | 500*500*73 | 500*500*73 | 500*500*73 |
| Cabinet Weight(±0.25kg) | 500*1000*73 | 500*1000*73 | 500*1000*73 | 500*1000*73 | 500*1000*73 |
| Cabinet Resolution(px*px) | 192*192 | 168*168 | 128*128 | 128*128/128*256 | 104*104/104*208 |
| Module Resolution(px*px) | 96*96 | 86*86 | 64*64 | 64*64 | 52*52 |
| Vertical Viewing Angle(Deg) | H160/V120 | H160/V120 | H160/V120 | H160/V120 | H160/V120 |
| Brightness(cd/m2) | 1000 | 1000 | 1000 | 4500 | 4500 |
| Gray Scale(bit) | 16 | 16 | 16 | 16 | 16 |
| Refresh Rate(Hz) | 3840 | 3840 | 3840 | 3840 | 3840 |
| Max Power Consumption(W/sqm) | 400 | 400 | 400 | 700 | 700 |
| Average Power Consumption(W/sqm) | 120 | 120 | 120 | 210 | 210 |
| Input Voltage(V) | AC 100-240 | AC 100-240 | AC 100-240 | AC 100-240 | AC 100-240 |
| Ingress Protection | IP43 | IP43 | IP43 | IP65 | IP65 |
| Working Environment | Indoor | Indoor | Indoor | Outdoor | Outdoor |
LED Stage Backdrop Screen OF Service Concept
We believe in taking the initiative, maintaining honesty and trustworthiness, which means we will respond quickly to customer questions and do everything possible to meet customer demands.
Q1: How to install led display?
A1: We will provide drawing of steel structure or hanging truss, then you can install led display very easy.
Q2: How can you ensure the led display product quality?
A2: All kinds of our screens have to do the aging test before leaving factory. And we also have waterproof test and shaking test to ensure the high-end level product quality.
Q3: How to deal with the faulty?
A3: Firstly, our products are produced in strict quality control system and the defective rate will be less than 0.2%. Secondly, during the guarantee period, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
4. WHAT IS THE PAYMENT TERMS?
30% deposit by TT, 70% balance before shipment.
