P6 P8 P10 RGB SMD Outdoor Fixed installation LED Screen Full Color Led Display Board For Advertising
P6 P8 P10 RGB SMD Outdoor Fixed Installation LED Screen Full Color Led Display Board For Advertising
Product of Outdoor LED Screenfeature:
1) With good lightening accordance and no mosaic
2) Can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment
3) Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced
4) High brightness, and can be adjustable, meets the need of changing requirement of customer in environment
5)usually use for advertising outdoor
| Model Outdoor LED Screen | P4 | P5 | P6 | P8 | P10 |
| Pixel Pitch(mm) | 4 | 5 | 6.67 | 8 | 10 |
| LED Chips | SMD1921 | SMD2525 | SMD3535 | SMD3535 | SMD3535 |
| Pixel density(dots/m2) | 62500 | 40000 | 22477 | 15625 | 10000 |
| Driving Method | 1/10 scanning | 1/8 scanning | 1/6 scanning | 1/5 scanning | 1/2 scanning |
| Module Size(mm) | 320*160 | 320*160 | 320*160 | 320*160 | 320*160 |
| Module Resolution | 80*40 | 64*32 | 48*24 | 40*20 | 32*16 |
| Cabinet Size( W*L mm) | 960*960 | 960*960 | 960*960 | 960*960 | 960*960 |
| Cabinet Material |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
| Cabinet Weight( Kg/m2 ) | 35 | 35 | 35 | 35 | 35 |
| Max.Consumption(W/m2) | 800 | 800 | 800 | 800 | 800 |
| Ave.Consumption(W/m2) | 350 | 350 | 350 | 350 | 350 |
| Brightness( Nits ) | ≥5500 | ≥5000 | ≥5500 | ≥5800 | ≥6000 |
| Viewing Angle (Vertical / Horizontal) | 120° / 120° | 120° / 120° | 120° / 120° | 120° / 120° | 120° / 120° |
| Refresh Rate | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz |
| IP Level | IP65 | IP65 | IP65 | IP65 | IP65 |
1) Corrugated Carton Package-- Economic option for fixed installation.
2) Plywood case--Fix installation--5-9 panels per case as customized
3) Flight case-- Rental Purpose--5-9 panels per case as customized
Outdoor LED Screen FAQ:
1: How is the ambient temperature of LED display screen?
When ambient temperature is too high or cooling condition is bad, users had better not to turn on the screen for a long time. Screen shall be installed in temperature from-10°C to 40°C. Over environment temperature range, temperature control equipment must be installed. It is forbidden to install LED display near any heat source.
Q2: How is the ambient humidity of LED display screen?
When installing screen, ambient relative humidity should be in the range from 30% to 70%. It is prone to get static electricity when the indoor humidity is below 30%; When the indoor humidity is higher than 70%, electronic components are easy to get damp.
Q3 : Can the LED display screen work at corrosive gas environment?
Please do not install the display in corrosive gas environment containing acid or base components, such as chemical warehouse.
