P4 P5 P6 P8 P10 Smd Outdoor Led Banner Display Cross Door Head Screen 6500nits
Advertising LED Display Screen P4 P5 P6 P8 P10 Outdoor Double-Sided Cross Screen Door Head Screen
Application of Advertising LED Display Screen:
It is widely used in advertising, sports, industrial enterprise, transportation, stations, terminals, airports, construction, education system and other public places.It characterized by perfect vivid image, super brightness, high refresh rate, long life span and stable work, and waterproof, etc.
| Advertising LED Display Screen | P4 | P5 | P6 | P8 | P10 |
| Pixel Pitch(mm) | 4 | 5 | 6.67 | 8 | 10 |
| LED Chips | SMD1921 | SMD2525 | SMD3535 | SMD3535 | SMD3535 |
| Pixel density(dots/m2) | 62500 | 40000 | 22477 | 15625 | 10000 |
| Driving Method | 1/10 scanning | 1/8 scanning | 1/6 scanning | 1/5 scanning | 1/2 scanning |
| Module Size(mm) | 320*160 | 320*160 | 320*160 | 320*160 | 320*160 |
| Module Resolution | 80*40 | 64*32 | 48*24 | 40*20 | 32*16 |
| Cabinet Size( W*L mm) | 960*960 | 960*960 | 960*960 | 960*960 | 960*960 |
| Cabinet Material |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
| Cabinet Weight( Kg/m2 ) | 35 | 35 | 35 | 35 | 35 |
| Max.Consumption(W/m2) | 800 | 800 | 800 | 800 | 800 |
| Ave.Consumption(W/m2) | 350 | 350 | 350 | 350 | 350 |
| Brightness( Nits ) | ≥5500 | ≥5000 | ≥5500 | ≥5800 | ≥6000 |
| Viewing Angle (Vertical / Horizontal) | 120° / 120° | 120° / 120° | 120° / 120° | 120° / 120° | 120° / 120° |
| Refresh Rate | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz |
| IP Level | IP65 | IP65 | IP65 | IP65 | IP65 |
Advertising LED Display Screen FAQ:
Q1: What details need to provide before get a quotation?
The buyer needs to provide pixel pitch, usage, dimension of screen and as more details as possible.
Q2: What are the terms of delivery?
We accept EXW, FOB, CFR, CIF, DDU or Express (fast delivery).
Q3: What is the viewing angle of the screens?
All of our LED screens have at least a wide 120° degree viewing angle. This means that the image still looks good and readable for 60° in each direction of the front of the screen left and right,
