Window Digital Led Poster Display Outdoor Shop Show Exhibition P1.87 P2.5
Digital Advertising Poster Customized Led Display for Shop Show / Exhibition P1.87 p2.5
Customized Led Display of Application
Applicable to shopping center, conference hall, control room, airport, station, supermarket, restaurant, can be as:
1. Advertising platform
2. Emergency notification and instant messaging
3. Information distribution of purchase information and supporting services
4. Publicity platform, brand demonstration window
| Pixel pitch | 1.8 mm Customized Led Display | 2.5mm Customized Led Display |
| Display Resolution | 320 x 1080 | 224*756 |
| OS | Android7.2 | Android7.2 |
| Weight | 38.4kg | 38.4kg |
| Color Depth | 14 bits | 14Bit |
| Refresh Rate | > 2880 Hz | >2880Hz |
| Control Ratio | 4000:1 | 4000:1 |
| Brightness | 480-800nits(8 level adjustable) | 480-800nits(8 level adjustable) |
| Viewing Angle | 160˚ (V) / 160˚ (H) | 140°(V) / 140°(H) |
| Signal Input | HDMI2.0*2; USB2.0*2 | HDMI2.0*2; USB2.0*2 |
| Audio Input | External Audio Interface | External Audio Interface |
| Control Input | RJ45, TOUCH-USB, WiFi | RJ45, TOUCH-USB, WiFi |
| Support Video Formate | MP4,AVI,WMV | MP4,AVI,WMV |
| AC Input Voltage | AC110~240V | AC110~240V |
| AC Input Rate | 50 ~ 60Hz | 50 ~ 60Hz |
| Max. Power Consumption | 570W /panel | 570W /panel |
| Average Power Consumption | 190W /panel | 570W /panel |
| Work temperature | 0 ~ 40˚C | 0 ~ 40˚C |
| Lifespan | ≥100,000 Hours | ≥100,000 Hours |
| Installation/ Maintenance Way | Brancing(standard)/hanging(optional)/wall mounted(optional)/Stacking base (optional)/ Modules front maintenance | Brancing(standard)/hanging(optional)/wall mounted(optional)/Stacking base (optional)/ Modules front maintenance |
Customized Led Display FAQ:
Q1:How to choose a led display?
You should consider 3 simple questions when you choose a led screen by yourself.
1. What's the environment- indoor or outdoor ?
2. Is it for rental use ( need to be moved from one place to another place frequently) or for fixed installation (to be installed in a place permanently)?
3. what is the approximate size of the led screen you would like to purchase?
Q2:Which pixel pitch should i choose?
There's a range of pixel pitch from 1.25--30mm, there is a roughly principle-usually small pixel(1.25mm-10mm) used for indoor led screen, bigger pixel (10mm-30mm) used for outdoor led screen( for example huge advertisement billboard on a big building).
Q3:Which control system should i choose?
There are two kind of control systems on the market-synchronous and asynchronous control system, And for big size led screen(usually more than 20sqm) need to use synchronous control system, below 20sqm it's up to you to use syn or asyn. But asyn control system's refresh rate is much lower than sync control system and which you can use wifi, 3G, 4G etc wireless to control.
