Smd3535 Wall Mounted Outdoor Fixed Led Display 4G WIFI 3G Building 320x160mm
Outdoor LED Screen WIFI 3G 4G Wall Mounted Fixed Installation Outdoor Billboard
Outdoor LED Screen Product Feature:
1. The first level LED chip from Taiwan Epistar
2. With pure golden wire connection in LED
3. Grand A row material for module frame and mask
4. 4 layers PCB and copper plating thickness > 18mil
5. Stainless steel screws when assembly
6. Disassembly and assembly are quick and easy
7. 3 to 5 years warranty
8 . Energy-saving 60% : driving with low frequency current, heat-dissipated roller fans with automatic temperature-controlling device.
9 . Life time >11 years;
|
Parameters |
P6.67 |
P8 |
P10 |
|
Pixel Configuration |
SMD2727 |
SMD3535 |
SMD3535 |
|
Pixel Pitch(mm) |
6.67 |
8 |
10 |
|
Pixel Density(dots /m²) |
22500 |
15625 |
10000 |
|
Module Size(L x W x H)/(mm) |
480x320 |
480x320 |
480x320 |
|
Panel Size(L x W x H)/( mm) |
960x960x105 |
960x960x105 |
960x960x105 |
|
Panel Material |
Iron |
Iron |
Iron |
|
Panel Weight(kg/m2) |
45 |
45 |
45 |
|
Color Depth(Bit) |
16 |
16 |
16 |
|
Gray Level |
65536 |
65536 |
65536 |
|
Refresh Rate(Hz) |
3840 |
3840 |
3840 |
|
Driver Method |
1/5 |
1/3 |
1/2 |
|
Brightness |
6000-10,000 |
6000-10,000 |
6000-10,000 |
|
Viewing Angle(H/V°) |
140/140 |
140/140 |
140/140 |
|
AC Power Input(V) |
AC220±10% |
AC220±10% |
AC220±10% |
|
AC Power Frequency(Hz) |
50/60 |
50/60 |
50/60 |
|
Max. AC Power Input (W/m²) |
550 |
550 |
550 |
|
Avg. AC Power Input (W/m²) |
170 |
170 |
170 |
|
Storage Temperature |
-40~60 |
-40~60 |
-40~60 |
|
Working Temperature |
-20~50 |
-20~50 |
-20~50 |
|
Storage Humidity |
10%~60%RH |
10%~60%RH |
10%~60%RH |
|
Working Humidity |
10%~60%RH |
10%~60%RH |
10%~60%RH |
|
IP Rating |
IP66 |
IP66 |
IP66 |
|
Life Span(hours) |
100000 |
100000 |
100000 |
|
Installation & Maintenance |
Front&Rear |
Front&Rear |
Front&Rear |
Outdoor LED Screen FAQ
Q1:What’s the function?
A1:Support various formats,like VGA,Video,AVI,DAT,etc.
Q2:How to install and install way.
A2:No need steel structure for installation to save a lot of cost,Have professional connector,Quick lock assembly 1 hour for 90 sqm installation
Q3:LED display modules are generally expressed in PX,such as P2 P3 P4...P8 P10,what does this mean?
A3:P3 P4...P8 P10 means that the pixel pitch is 3mm 4mm...10mm,which determines resolution of a display.Pixel pitch smaller,led resolution higher.
Q4:What pixel pitch should I choose on my display?
A4:It’s mainly depends on the viewing distance,the size of the display screen,the desired effect the application scenario and the customer budget.
