160x320mm P4 P5 P6 Advertising LED Display Screen Outdoor SMD1921

Price Negotiable
Price: $985.00/Square Meters 6-49 Square Meters
MOQ: 6 Square Meters
Delivery Time: 15 working days
Brand: King VisionLed
Product Description

160*320mm LED Screen P4 P5 P6Outdoor Advertising LED Display Screen SMD1921



The 160*320mm P4RGB module is the replacement for P10 LED Screen also. It's with same size as P10 LED,

but with more dense LED arrangement which makes the LED Signs is more clear than P10 LED Display. The LED

Screen adopts physical and virtual pixel technology which makes the picture more clear and vivid, no flicker and

blind dots. The LED Screen is with IP65 waterproof and dust proof cabinet design, and with super high brightness

LED, so it works well in rain and sunshine day. With lock design, it can be installation friendly as well.



Features:

1: Module size for P4RGB LED module is 160*320mm

2: High brightness 5000mcd which can be seen in daytime

3: Programmable software, support world language text, photos and video.

4: UL Certified Meanwell power supply has been used to make sure realiable quality.

5: Standard steel cabinet with easy installation design, maintenance from back side. Available for aluminum cabinet

if needed

6: Standard cabinet size: 640*640mm, 960*960mm, welcome for customized size.



Advertising LED Display Screen P4 P5 P6 P8 P10
Pixel Pitch(mm) 4 5 6.67 8 10
LED Chips SMD1921 SMD2525 SMD3535 SMD3535 SMD3535
Pixel density(dots/m2) 62500 40000 22477 15625 10000
Driving Method 1/10 scanning 1/8 scanning 1/6 scanning 1/5 scanning 1/2 scanning
Module Size(mm) 320*160 320*160 320*160 320*160 320*160
Module Resolution 80*40 64*32 48*24 40*20 32*16
Cabinet Size( W*L mm) 960*960 960*960 960*960 960*960 960*960
Cabinet Material

Magnesium

Alloy

Magnesium

Alloy

Magnesium

Alloy

Magnesium

Alloy

Magnesium

Alloy

Cabinet Weight( Kg/m2 ) 35 35 35 35 35
Max.Consumption(W/m2) 800 800 800 800 800
Ave.Consumption(W/m2) 350 350 350 350 350
Brightness( Nits ) ≥5500 ≥5000 ≥5500 ≥5800 ≥6000
Viewing Angle (Vertical / Horizontal) 120° / 120° 120° / 120° 120° / 120° 120° / 120° 120° / 120°
Refresh Rate ≥1920Hz ≥1920Hz ≥1920Hz ≥1920Hz ≥1920Hz
IP Level IP65 IP65 IP65 IP65 IP65





Advertising LED Display Screen Our service:

1. Any inquiry or complaint will be replied within 24hrs.
2. Providing competitive products and sales consultation.

3. Any your customized product or idea we can help you to design and put into product.

4. Three-year quality guarantee, only needs to anew purchase the raw material when over the warranty period.

5. Protection of your sales area, ideas of design and all your private information.

6.Years of production experience we can very good to control the quality of the product, OEM and ODM accepted
