CE Certificate Fuel Injector Tester And Cleaner 500mm Width 670mm Height

Ultrasonic Cleaning Machine Cleaner Car 6 Cylinder Electronic Tool Fuel Injector Tester

About Machine Details

WDF-GDI injector cleaning and testing machine is designed with wide voltage technology and is suitable for 110V and 220V voltage. It is combined with ultrasonic cleaning technology and microprocessor hydraulic control cleaning detection technology. Fuel pump oil supply simulates low, medium and high engine conditions, cleaning and testing the fuel injectors of the automobile; ultrasonic cleaning can simultaneously clean multiple injectors, which can effectively and completely remove carbon deposit for the automobiles injectors.

Equipment Description :

This equipment is composed of 2 different parts:

1. Work bench

2. Ultrasonic washing tank

3. Control Screen

Installation :

1. All equipment are delivered with 3 pin electrical cable, use the ground connection for equipment and operator protection.

2. Verify that test liquid level at 2.5L or at least between the range of two red lines. For a new machine, please fill 2.0~ 2.5L testing liquid. Never fill up the tank at its maximum capacity.

3. Fill up the ultrasonic cleaning tank with the liquid for injector cleaning. Liquid level should not reach 3 cm below the tank edge, in order to avoid liquid overflow on device. Take special care not to drop liquid on the equipment when filling up or emptying the tank.
