7KW 32A EV Charging Extension Cable IP65 J1772 Electric Car Extension Cords
CE Home 7KW 32A EV Charging Gun 1-Phase AC Charging Cable For EV IP65
Product Parameters
| Product name | EV Charging Extension Cable | ||
|
Infrastructure plug:
|
AC-YCX3-32A-LT
|
||
|
Rated power
|
7kW
|
||
|
Output
|
32A
|
||
|
No. of phases
|
1-phase
|
||
|
Contact resistance
|
≤0.3mΩ (L/N)
|
||
|
Isolation resistance
|
500MΩ (1000V AC)
|
||
|
High voltage resistance
|
2600V AC
|
||
|
Resistor coding
|
680Ω
|
||
|
Contact thermal rise
|
≤50K
|
||
|
Charge mode
|
IEC 62196-2, IEC 61851-1
|
||
|
Working humidity
|
5%-95%non condensed
|
||
|
Protection type
|
IP55 (plugged in)
|
||
|
Flammability
standard
|
UL94 V-0
|
||
|
Withdrawal force
|
45N…80N
|
||
|
Pluging cycles
|
≥10000x (no load)
|
||
|
Operating
temperature
|
-25°C...+55°C
|
||
|
Cable
|
5*2.5mm2 + 1*0,75mm2
|
||
|
Weight
|
2100g
|
||
Feature of product
1. The EV charging connector interface design conforms to ICE62198-2 TYPE2 regulations and standards;
2. The charging plug is ergonomic and easy to operate
3. The product has excellent protection and can withstand harsh outdoor environment and climate;
4. Anti-vehicle rolling;
5. The EV charging plug has passed CE certification;
6. Applicable to connection method B of IEC61851.
Product application field
Applied to pure electric vehicle (BEV), plug-in hybrid electric vehicle (PHEV), charging pile
