Medical Hospital 5mmPb Mri X Ray Lead Glass Transparent
Medical hospital MRI transparent medical x-ray lead glass cristal plomado precios
Quick Detail:
· Available with lead-lined telescoping frames for walls or lead-lined vision frames for doors
· Many x-ray protective shielding levels are available
· With frame and without frame both available
Description:
The function of lead glass:
the main performance of lead glass is optically clear and transparent protective shielding.
A low optical quality protective glass plate with prescribed attenuation performance is used,
and its attenuation performance is 0.22mmpb per millimeter; applicable scope It can be installed
in the observation window laboratory of X-ray detection and CT scanning.
The lens of the protective window goggles.
The X-ray screen of the airport security inspection and the protective window for industrial flaw detection.
In radiology medicine, it is often used for radiation protection and shielding, or Observation window for the lead room for filming.
ZF series high-lead glass products adopt advanced production technology and optical detection methods.
The materials are made of high-lead content optical glass. They have the characteristics of clean internal materials, good transparency, large lead equivalent, and strong anti-radiation ability. , It can effectively block X-rays, gamma rays, cobalt 60 rays, and isotope scanning.
ZF2, ZF3 series of high-lead glass is widely used in X-ray diagnosis and spiral CT scanning room observation window, medical diagnostic shielding; ZF6, ZF7 series of high-lead glass is mainly used in nuclear power plants, nuclear energy applications, and other nuclear industries.
Specification:
|
8mm (1.7mmpb) |
10mm (2.1mmpb) |
12mm (2.6mmpb) |
15mm (3.3 mmpb) |
18mm (3.96 mmpb) |
20mm (4.4 mmpb) |
25mm (6.71 mmpb) |
|
| 200*300 | 200*300*8 | 200*300*10 | 200*300*12 | 200*300*15 | 200*300*18 | 200*300*20 | - |
| 300*400 | 300*400*8 | 300*400*10 | 300*400*12 | 300*400*15 | 300*400*18 | 300*400*20 | - |
| 400*600 | 400*600*8 | 400*600*10 | 400*600*12 | 400*600*15 | 400*600*18 | 400*600*20 | - |
| 600*800 | 600*800*8 | 600*800*10 | 600*800*12 | 600*800*15 | 600*800*18 | 600*800*20 | - |
| 600*900 | 600*900*8 | 600*900*10 | 600*900*12 | 600*900*15 | 600*900*18 | 600*900*20 | - |
| 1000*800 | 1000*800*8 | 1000*800*10 | 1000*800*12 | 1000*800*15 | 1000*800*18 | 1000*800*20 | 1000*800*25 |
| 1200*800 | 1200*800*8 | 1200*800*10 | 1200*800*12 | 1200*800*15 | 1200*800*18 | 1200*800*20 | 1200*800*25 |
| 1200*900 | 1200*900*8 | 1200*900*10 | 1200*900*12 | 1200*900*15 | 1200*900*18 | 1200*900*20 | 1200*900*25 |
| 1200*1000 | 1200*1000*8 | 1200*1000*10 | 1200*1000*12 | 1200*1000*15 | 1200*1000*18 | 1200*1000*20 | 1200*1000*25 |
| 1200*1200 | - | 1200*1200*10 | 1200*1200*12 | 1200*1200*15 | 1200*1200*18 | 1200*1200*20 | 1200*1200*25 |
| 1500*900 | - | 1500*900*10 | 1500*900*12 | 1500*900*15 | 1500*900*18 | 1500*900*20 | 1500*900*25 |
| 1500*1000 | - | 1500*1000*10 | 1500*1000*12 | 1500*1000*15 | 1500*1000*18 | 1500*1000*20 | 1500*1000*25 |
| 1500*1200 | - | 1500*1200*10 | 1500*1200*12 | 1500*1200*15 | 1500*1200*18 | 1500*1200*20 | 1500*1200*25 |
| 1600*1000 | - | 1600*1000*10 | 1600*1000*12 | 1600*1000*15 | 1600*1000*18 | 1600*1000*20 | 1600*1000*25 |
| 1600*1200 | - | 1600*1200*10 | 1600*1200*12 | 1600*1200*15 | 1600*1200*18 | 1600*1200*20 | 1600*1200*25 |
| 1800*1000 | - | 1800*1000*10 | 1800*1000*12 | 1800*1000*15 | 1800*1000*18 | 1800*1000*20 | 1800*1000*25 |
| 1800*1200 | - | 1800*1200*10 | 1800*1200*12 | 1800*1200*15 | 1800*1200*18 | 1800*1200*20 | 1800*1200*25 |
| 2000*1000 | - | 2000*1000*10 | 2000*1000*12 | 2000*1000*15 | 2000*1000*18 | 2000*1000*20 | 2000*1000*25 |
| 2000*1200 | - | 2000*1200*10 | 2000*1200*12 | 2000*1200*15 | 2000*1200*18 | 2000*1200*20 | 2000*1200*25 |
| 2400*1200 | - | 2400*1200*10 | 2400*1200*12 | 2400*1200*15 | 2400*1200*18 | 2400*1200*20 | 2400*1200*25 |
Application:
It is mainly used for diagnostic X-ray machine rooms, CT, ECT, PET, ct-pet, and other machine rooms,
as well as observation of Windows on the protective screen of protective doors.
It is mainly used in manufacturing optical instruments, art vessels, etc.
It is also a medical X-ray radiation-proof lead glass plate in the medical field.
FAQ:
Q1. Can I have a sample order for lead glass?
A: Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: Usually 5-7 working days.
Q3. Do you have any MOQ limit for led light orders?
A: Low MOQ, 1pc is available.
