China Material Save Automatic Injection Moulding Machine 450 Ton Injection Molding Machine for sale

Material Save Automatic Injection Moulding Machine 450 Ton Injection Molding Machine

Price Negotiable

Price: Negotiable

MOQ: 1

Delivery Time: 45 days

Brand: OUCO

Product Description

OUCO 450 Ton Plastic Automatic Injection Molding Machine, Raw Material Save

Leading technology and performance
China unique producer, central locking toggle
Injection molding compounders (CIML) fill the blank in Asia
Electro-hydraulic hybrid 2 platen machines are special for automotive industry with the leading level

Product Parameters

机型			300T			400T			500T			600T
螺杆规格			A	B	C	A	B	C	A	B	C	A	B	C
螺杆直径	Screw diameter	mm	50	60	65	65	75	80	70	75	85	75	85	90
螺杆长径比	Screw L/Dratio		22	22	22	22	22	22	22	22	22	22	22	22
理论注射容积	Theoretical injection volume	cm3	638	918	1078	1C75	1431	1628	1481	1700	2184	1788	2297	2575
注射重量(PS)	Shot weight (PS)	g	593	853	1002	1C11	1345	1530	1377	1581	2031	1645	2113	2369
注射速率	injection rate(Ps)	g/S	330	475	558	426	568	646	G03	693	890	G13	788	884
注射压力	Injection pressure	MPa	286	198	169	242	182	160	209	182	142	204	159	142
注射行程	Inject on stroke	mm	325			360			385			405
最大注射速度	Max. injection speed	mm/s	178			156			166			157
最大摞杆转速	Screw speed	r/min	0-200			0-200			0-200			0-200
系统压力	Sys. Pressure	MPa	16			16			16			16
电机总功率	Pump Motor(Min-Max)	kW	63			75			94			101
油泵排量	Displacement	ml/r	163			100+100			125+125			160+125
电机数员	number of Motors	PC	1			2			2			2
电热功率	Heater power	kW	27			35			41			47
温控区数	Number of temp. control zones		5+1			5+1			5+1			5+1
锁模力	Clamping force	kN	3000			4000			5000			6000
开模行程	Clamping stroke	mm	800			900			1000			1150
拉杆内间距	Tie bar distance W×L	mmxmm	680x680			760x660			860x760			960x860
最小模具厚度	Min. mold thickness	mm	210			300			300			350
最大模具厚度	Max. mold thickness	mm	680			730			800			920
顶出行程	Ejector stroke	mm	190			190			210			210
顶出力	Ejector force forward	kN	62			80			110			113
顶出杆数	Number of ejector bar	PC	1+12			1+12			1+12			1+12
油箱容量	Oil tank capacity	L	510			680			850			940
机械外形尺寸(约)	Machine dimensions(LxWxH)	mxmxm	7.7x1.8x1.8			8.2x1.9x1.9			87x2.0x2.1			9.3x2.1x2.3
机器重量(约)	Machine weight	Ton	10.5			15			19			23
