China 530 Ton High Efficiency Automated Injection Molding Machine PVC Parts Molds for sale

530 Ton High Efficiency Automated Injection Molding Machine PVC Parts Molds

Price Negotiable

Price: Negotiable

MOQ: 1

Delivery Time: 2 months

Brand: OUCO

Product Description

530 Ton PVC Injection Molding Machine Suitable For Easy Installation of PVC Parts Molds

Product Details
1. PVC material with special screw + barrel design and added fan for cooling barrel to avoid material overheating and coking;

2. Add a larger grade of oil motor to facilitate the plasticization and molding of PVC material;

3. Extended security door width for better installation of PVC parts molds, suitable for easy installation of PVC parts molds (core extraction barrels);

4. Provide special technical solutions for PVC injection molding, not only for the modification of screw and barrel, but also for the complete hydraulic system and special solutions for injection device.
TECHNICAL PARAMETER

TECHNICAL PARAMETER TABLE
Injection Unit
Screw diameter	mm	80
Screw L/D ratio	L/D	20
Injection capacity in theory	cm³	1860
Injection weight(PVC)	g	2232
Injection pressure	MPa	168
Injection rate	g/s	522
Plasticizing capacity	g/s	69
Screw speed	rpm	150
Clamping Unit
Clamping force	KN	5300
Moving mould-plate stroke	mm	830
Max.Mould height	mm	830
Min.Mould height	mm	330
Space between tie-bars	mm	860x810
Hydraulic ejector force	KN	181
Hydraulic ejector stroke	mm	230
Ejector number	n	17
Other
Pump pressure	MPa	16
Motor/Driving power	KW	30x2
Heating capacity	KW	26.45
Machine dimension	m	8.1x2.54x2.5
Machine weight	t	19.9
Oil tank capacity	L	969
