OUCO 280T Energy Saving Hydraulic Servo Plastic Desk Organizer File Tray Injection Molding Machine

Price Negotiable
Price: Negotiable
MOQ: 1
Delivery Time: 2 months
Brand: OUCO
Product Description

OUCO 280T Energy Saving Hydraulic Servo Plastic Desk Organizer File Tray Injection Molding Machine

We have attracted and trained a large number of skilled and highly educated equipment operators, providing a solid guarantee for the high-precision processing and production of products. We continuously optimize production to ensure that customers can achieve excellent performance and extremely high production efficiency when using injection molding machines. We have a variety of screws with different diameters to choose from according to the different product requirements of our customers, which have a wide range of adaptability. The excellent machine quality and price advantage provide us with the driving force to continue moving forward in the injection molding machine market.



Product Advantages



OC-280H will inject efficient, precise and reliable power into your production line. In the design of the injection molding machine, a direct-pressure external curved center clamping structure is adopted. The template is evenly stressed and has small deformation, which plays a positive protective role. The hydraulic system is provided by well-known manufacturers across the country, with large flow, low noise and stable performance. In the injection unit, the dual-rail injection technology enables fast injection response and high product molding accuracy. Whether you are pursuing efficient production or focusing on product quality and environmental protection, our injection molding machines can meet your diverse needs.

                                                                 MODEL OC280H
Clamping force (kN) 2800
Space between tie bar (mm*mm) 610*510
Max. mold thickness (mm) 250
Min. mold thickness(mm) 650
Opening stroke (mm) 700
Ejector stroke(mm) 190
Ejector force forward(Kn) 62
Screw diameter(mm) 65
Screw L/D ratio 22
Theoretical injection volume (cm3) 994
Shot weight (PS) g 914
Injection pressure(MPa) 143
Screw speed (rpm) 0-200
Injection Rate(g/s) 359
Motor power (Kw) 40
Oil tank capacity(L) 510
Heater power (Kw) 27
Machine Weight (Ton) 11
Machine size L×W×H (m) 8.1*1.9*2.0
