70 Psi Tyre Pressure Gauge Hose Rapid Deflate Bottom Mechanical Pressure Gauges

Price Negotiable
Price: Negotiable
MOQ: 100 Pieces
Delivery Time: 3~4 Weeks
Brand: WESEN or Customized
Product Description

2" 70 psi Mechanical Tire Gauges with Hose Rapid Deflate Function Tire Pressure Gauge



Des​cription

Keeping your car tires properly inflated is an easy maintenance chore that's vital to your safety. Under-inflated tires build up excess heat as you drive, which can result in tire failure. With too little air pressure, tires can also wear faster and unevenly, waste fuel, and negatively impact the vehicle's braking and handling. To help maintain tires in top condition, use a tire-pressure gauge to check the pressure of your tires at least once a month and before starting on any long trip. For an accurate read, make sure the car has been parked for three or more hours before checking the tire pressure.



Special features

Mechanical design, no batteries needed

Reliable performance, robust body with rubber cover

360 degree swive, easy to operate

Durable air valve button



Specifications

Design

EN 837-1

Nominal size

50mm

Accuracy

2.5
Pressure range 70 psi (customized)

Working pressure

Steady: full scale value

Fluctuating: 0.9 x full scale value

Short time: 1.3 x full scale value

Usage circumstances

Indoor, outdoors

Ingress protection

IP66

Temperature effect

When the temperature at the measuring system deviates from the reference temperature +20 °C [+68 °F]: ≤ ±0.4 %/10 °C [≤ ±0.4 %/18 °F] of full scale value

Process connection

Painted steel

Pressure element

Bourdon tube
Movement Brass
Dial Aluminium
Pointer Aluminium
Case Painted steel
Window PC
Unit

bar, psi, kg/cm2, kPa, MPa

Thread Customized
Options Other process connections



Operating Instructions

Use the vehicle's recommended pressure, do not exceed the "max pressure" figure found on the tire sidewall.
Check pressure when tires are cold and have sat for at least one hour.
Removing cap from inflation valve, place the gauge chuck firmly onto tire valve stem and press down evenly. If air escapes, apply more pressure until air stops escaping.
Remove gauge from valve stem to read tire pressure.
If tire pressure is too high, refit the tire pressure gauge to valve stem then gently press pressure release button until recommended pressure is reached.

If tire pressure is low, inflate to the recommended pressure then recheck.
Store tire pressure gauge in a safe, dust free area.



Ordering information

Model / Dial size / Pressure Range / Process connection / Options
