2.5" Dial 11 bar Oil Manometer 316 SS Tube/Socket All Stainless Steel Pressure Gauge for Petrochemical Industries
2.5" Dial 11 bar Oil Manometer 316 SS Tube/Socket All Stainless Steel Pressure Gauge for Petrochemical Industries
Description
Brass is an economical and suitable option for many applications. However, for corrosion resistance, extreme temperatures, and overall system integrity, choose a stainless steel pressure gauge.
Gauges with copper alloy (brass) wetted parts – socket, end piece, Bourdon tube, etc. – are excellent options for use around hydraulic oil, water, air, and other non-aggressive liquids and gases. However, only stainless steel resists the corrosion that can lead to system breaches and gauge failure. In general, use a stainless steel gauge around ammonia, creosote, aggressive solvents, or other harsh chemicals.
Applications
Intended for adverse service conditions where pulsating or vibration exists
Chemical and petrochemical, power stations, mining, on and offshore, environmental technology, mechanical engineering and plant construction
Suitable for gaseous or liquid media that will not obstruct the pressure system
Special features
Excellent load cycle stability and shock resistance
Design per EN 837-1
Completely from stainless steel
Pressure ranges up to 15,000 psi
|
Design |
EN 837-1 |
|
Nominal size |
63mm |
|
Accuracy |
Class 1.6 |
| Pressure range | 11 bar (customized) |
|
Pressure limitation |
Steady: 3/4 x full scale value |
| Medium temperature |
Unfilled gauge: -40 ... +200 °C [-40 ... +392 °F] Gauge with glycerine filling: -20 ... +100 °C [-4 ... +212 °F] Gauge with silicone oil filling: -40 ... +100 °C [-40 ... +212 °F] |
|
Ambiet temperature |
Unfilled gauge: -40 ... +60 °C [-40 ... +140 °F] Gauge with glycerine filling: -20 ... +60 °C [-40 ... +140 °F] Gauge with silicone oil filling: -40 ... +60 °C [-40 ... +140 °F] |
|
Temperature effect |
When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.4 %/10 K of the span |
|
Process connection |
Stainless steel, SUS 304, SUS 316 |
|
Pressure element |
Stainless steel, C-type or helical type |
| Movement | Stainless steel |
| Dial | Aluminium, white, with pointer stop pin Black and red lettering |
| Pointer | Aluminium, adjustable type |
| Case | Stainless steel |
| Ring | Bayonet ring, stainless steel |
| Window | Plastic, glass |
| Unit |
bar, psi, kg/cm2, kPa, MPa |
| Thread | 1/4 G, BSP, PT, BSPT, NPT |
| Options | Other process connection Surface mounting flange Mounting bracket |
Dimensions
Ordering information
Model / Dial size / Pressure Range / Process connection / Options
