6" 100 bar Silicone Oil Manometer SUS 316 Tube/Socket 1/2 BSP Blow Out Protection All Stainless Steel Pressure Gauge
6" 100 bar Silicone Oil Manometer SUS 316 Tube/Socket 1/2 BSP Blow Out Protection All Stainless Steel Pressure Gauge
Description
Wesen Bourdon gauges are known in the industry for their superior sensitivity and accuracy. They are widely used in industries like Chemical Processing, Petroleum Refinery, Petrochemical, Fertilizer, Thermal and Nuclear Power Generation and others. Our Bourdon gauges can pressures up to 1000 kg/cm2. With an IP68 rating (IS/IEC 60529:2001), they are completely dust proof and can handle complete continuous submersion in water. Choose from a range of selections for our wetted parts like SS304, SS316 or SS316L stainless steel. We give due consideration to international standards for durability, accuracy and quality of workmanship. With this assurance, you can trust Wesen will accurately fulfill all of your pressure measuring requirements.
Applications
Intended for adverse service conditions where pulsating or vibration exists
Chemical and petrochemical, power stations, mining, on and offshore, environmental technology, mechanical engineering and plant construction
Suitable for gaseous or liquid media that will not obstruct the pressure system
Special features
Excellent load cycle stability and shock resistance
Design per EN 837-1
Completely from stainless steel
Pressure ranges up to 15,000 psi
|
Design |
EN 837-1 |
|
Nominal size |
150mm |
|
Accuracy |
Class 1.0 |
| Pressure range | 100 bar (customized) |
|
Pressure limitation |
Steady: 3/4 x full scale value |
| Medium temperature |
Unfilled gauge: -40 ... +200 °C [-40 ... +392 °F] Gauge with glycerine filling: -20 ... +100 °C [-4 ... +212 °F] Gauge with silicone oil filling: -40 ... +100 °C [-40 ... +212 °F] |
|
Ambiet temperature |
Unfilled gauge: -40 ... +60 °C [-40 ... +140 °F] Gauge with glycerine filling: -20 ... +60 °C [-40 ... +140 °F] Gauge with silicone oil filling: -40 ... +60 °C [-40 ... +140 °F] |
|
Temperature effect |
When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.4 %/10 K of the span |
|
Process connection |
Stainless steel, SUS 304, SUS 316 |
|
Pressure element |
Stainless steel, C-type or helical type |
| Movement | Stainless steel |
| Dial | Aluminium, white, with pointer stop pin Black and red lettering |
| Pointer | Aluminium, adjustable type |
| Case | Stainless steel |
| Ring | Bayonet ring, stainless steel |
| Window | Plastic, glass |
| Unit |
bar, psi, kg/cm2, kPa, MPa |
| Thread | 1/2 G, BSP, PT, BSPT, NPT |
| Options | Other process connection Surface mounting flange Mounting bracket |
Dimensions
Ordering information
Model / Dial size / Pressure Range / Process connection / Options
