EN 837-1 1.6 MPa All Stainless Steel Pressure Gauge Blow Out Protection 1/2 PT SUS 316
6" Dia.1.6 MPa Lower Back Manometer SUS 316 Tube/Socket 1/2 PT Blow-out Protection All Stainless Steel Pressure Gauge
Description
A wide range of all stainless steel construction gauges, dry or dry fillable, are stocked for typical use in the food and drink, pharmaceutical and petrochemical process industries.
Stainless steel (SS316) internals and wetted parts make the gauge more resistant to corrosive or high temperature substances entering the gauge. However, please contact us should you have any doubt about high process temperatures or the suitability of SS316 with your measured substance. Many alternative materials and options are available.
For the measurement of fluid liquids that are not:- highly viscous, high temperature (over 150°C) or likely to solidify/crystallize.
Applications
Intended for adverse service conditions where pulsating or vibration exists
Chemical and petrochemical, power stations, mining, on and offshore, environmental technology, mechanical engineering and plant construction
Suitable for gaseous or liquid media that will not obstruct the pressure system
Special features
Excellent load cycle stability and shock resistance
Design per EN 837-1
Completely from stainless steel
Pressure ranges up to 15,000 psi
|
Design |
EN 837-1 |
|
Nominal size |
150mm |
|
Accuracy |
Class 1.6 |
| Pressure range | 1.6 MPa (customized) |
|
Pressure limitation |
Steady: 3/4 x full scale value |
| Medium temperature |
Unfilled gauge: -40 ... +200 °C [-40 ... +392 °F] Gauge with glycerine filling: -20 ... +100 °C [-4 ... +212 °F] Gauge with silicone oil filling: -40 ... +100 °C [-40 ... +212 °F] |
|
Ambiet temperature |
Unfilled gauge: -40 ... +60 °C [-40 ... +140 °F] Gauge with glycerine filling: -20 ... +60 °C [-40 ... +140 °F] Gauge with silicone oil filling: -40 ... +60 °C [-40 ... +140 °F] |
|
Temperature effect |
When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.4 %/10 K of the span |
|
Process connection |
Stainless steel, SUS 304, SUS 316 |
|
Pressure element |
Stainless steel, C-type or helical type |
| Movement | Stainless steel |
| Dial | Aluminium, white, with pointer stop pin Black and red lettering |
| Pointer | Aluminium, adjustable type |
| Case | Stainless steel |
| Ring | Bayonet ring, stainless steel |
| Window | Plastic, glass |
| Unit |
bar, psi, kg/cm2, kPa, MPa |
| Thread | 1/2 G, BSP, PT, BSPT, NPT |
| Options | Other process connection Surface mounting flange Mounting bracket |
Dimensions
Ordering information
Model / Dial size / Pressure Range / Process connection / Options
