6AWG 8AWG 10 Awg Silicone Wire RC Electrical Cable Harness Assembly 600V
Electrical Cable Assembly RC Soft High Temperature Silicone Wire 6AWG 8AWG 10AWG 12 14 16 18 20 22 AWG Cable Red Black
"Quality first, customer first" is our development policy, to provide customers with one-stop product supply program, and constantly improve our products and service system is the mission of the company.
Specification table:
|
Specifications (AWG) |
Copper wire shares (compos.NO./mm) |
Insulation thickness (mm)
|
Diameter (mm) |
Overall diameter (mm) |
Conductor resistance (Ohm/km) |
Sectional area (mm2) |
Carrying current (ampere) |
packing (M/coils) |
| 6AWG | 3200/0.08mm | 1.65 | 5.2 | 8.5 | 1.21 | 16.08 | 300 | 100 |
| 8AWG | 1650/0.08mm | 1.2 | 4.4 | 6.3 | 4.1 | 8.29 | 190 | 100 |
| 10AWG | 1050/0.08mm | 5.28 | 2.92 | 5.5 | 6.3 | 5.3 | 140 | 100 |
| 12AWG | 680/0.08mm | 3.42 | 2.41 | 4.5 | 9.8 | 3.4 | 88.4 | 100 |
| 14AWG | 400/0.08mm | 2 | 1.85 | 3.5 | 15.6 | 2.07 | 55.6 | 200 |
| 16AWG | 252/0.08mm | 1.3 | 1.47 | 3 | 24.4 | 1.27 | 35 | 200 |
| 18AWG | 150/0.08mm | 0.75 | 1.13 | 2.3 | 39.5 | 0.75 | 22 | 200 |
| 20AWG | 100/0.08mm | 0.5 | 0.92 | 1.8 | 62.5 | 0.5 | 13.87 | 400 |
| 22AWG | 60/0.08mm | 0.3 | 0.72 | 1.7 | 88.6 | 0.33 | 8.73 | 400 |
| 24AWG | 40/0.08mm | 0.2 | 0.58 | 1.6 | 97.6 | 0.2 | 5 | 400 |
| 26AWG | 30/0.08mm | 0.15 | 0.44 | 1.5 | 123 | 0.14 | 3.5 | 400 |
| 28AWG | 16/0.08mm | 0.08 | 0.32 | 1.2 | 227.2 | 0.08 | 1.25 | 100 |
| 30AWG | 11/0.08mm | 0.055 | 0.3 | 0.8 | 331 | 0.06 | 0.8 | 100 |
Description :
2AWG:Red Black
4AWG:Red Black
6AWG:Red Black Blue
8AWG:Red Black Blue White Yellow Green Orange
10AWG:Red Black Blue White Yellow Green Orange
12AWG:Red Black Blue White Yellow Green Orange
13AWG:Red Black Blue White Yellow Green Orange
14AWG:Red Black Blue White Yellow Green Orange
16-30AWG:Red Black Blue White Yellow Green Orange
After several years' efforts,we have established good and stable business cooperation with our customers from South Asia,East Asia,
North America,South America,Europe etc.Now our customers from more than 60 countries and areas.
As the development of our company,we built up our own professional technical team,mainly design and research
the manufacturing of wiring harness and cables,EV charging Cables & power cord cables etc,welcome to send your specification sheet for us to check,tks.
