600W 84V charge lead acid battery with lithium charger 5A 72V 7A 60V 8A 48V 10A 36V 15A 24V 12V 20A Lead Acid LiFePO4
Lithium Battery Charger 600W 84V 5A 72V 7A 60V 8A 48V 10A 36V 15A 24V 12V 20A Lead Acid LiFePO4 Lithium Battery charger
Specifications:
| Model: | OK-CH-600 | Max Power: | 600W |
| Shell: | Aluminium profile | Output: | Customizable |
| AC Input: | 85V-145Vac/185-265Vac | Waterproof: | IPx4 |
| Max Efficiency: | >=89% | Operating Temperature: | -30 to 65℃ |
| Storage Temperature: | -40 to 95℃ | Noise: | <=40dB |
| Cooling: | Active cooling with fan,nature cooling | ||
| Protection: |
Input low-voltage&over-voltage protection Overheat protection Output empty-load protection Output short&reverse protection Output over-current&over-voltage protection Automatic shutdown when fully charged |
||
Common Output:
| Common Output | ||||||
| Model | Nominal Voltage | Lead Acid | LiFePO4 | NCM/NCA | Max Charge Current | Dimensions |
|
E6 |
12V | 14.7V | 14.6V | 16.8V | 20A |
Size:205*105*68mm |
| 24V | 29.4V | 29.2V | 29.4V | 20A | ||
| 36V | 44.1V | 43.8V | 42V | 15A | ||
| 48V | 58.8V | 58.4V | 58.8V | 10A | ||
| 60V | 73.5V | 73V | 67.2V | 8A | ||
| 72V | 88.2V | 87.6V | 84V | 7A | ||
| 84V | 102.9V | / | 100.8V | 6A | ||
| 96V | 117.6V | / | 117.6V | 5A | ||
| Remark | Our chargers can be made for all kind of Lead acid and Lithium battery.We also can customize output voltage and current according to your request.Please contact us to confirm more details. | |||||
LED Indicator
For Lithium Battery:
1,When LED light is green,the charger is ready to charge or charging is complete.
2,When Green light is blinking,the charger is charging.
3,When Red light is blinking quickly,Input power failure.
4,When Red and green light is blinking alternately,the output is short-circuited or connection is reversed.
5,When Red light blinks 2 times,interval 1 second,then blinks 2 times again ,the charger temperature overheating alarm.
6,When Red light blinks 3 times,,interval 1 second,then blinks 3 times again ,the output over-current alarm.
7,When Red light blinks 4 times,,interval 1 second,then blinks 4 times again,the Output over-voltage alarm.
