Smes Sa213 Alloy Seamless Steel Pipe For Boiler Heat Exchanger
Price:
Negotiable
MOQ:
0.5Ton
Delivery Time:
7-15 work days
Brand:
hongcheng
Product Description
Astm A213 / Smes Sa213 Alloy Steel Seamless Tubes For Boiler Heat Exchanger Alloy Seamless Steel Pipe
Hongcheng Company supply huge qty of Cr-Mo Alloy seamless pipe and tube , and export more than 40 countries . Our alloy seamless tube be width used in boiler and heating.
Hongcheng controls the entire manufacturing process from raw material to finished products, Inspection points are localed in the manufacturing process to ensure all products meet all requirements. In such quality control system, faults are detected at the earliest possible stage of the production process in order to eliminate the risk of rejection at final inspection. We have made continuous efforts to reduce the problem throughout total quality assurance system including traceability control, Hongchengg not only inspect by ourself , also through TPI like BV, SGS, DNV, ABS, MOODY, IBR, so that today the quality of our productsis clearly recognized by our client.
ASTM A213/ASME SA213 T2, T11, T12, T22, T91, T92 Chemical Composition and Mechanical Properties
Grade |
Chemical Composition% |
||||||||
C |
Si |
Mn |
P, S Max |
Cr |
Mo |
Ni Max |
V |
Al Max |
|
T2 |
0.10~0.20 |
0.10~0.30 |
0.30~0.61 |
0.025 |
0.50~0.81 |
0.44~0.65 |
– |
– |
– |
T11 |
0.05~0.15 |
0.50~1.00 |
0.30~0.60 |
0.025 |
1.00~1.50 |
0.44~0.65 |
– |
– |
– |
T12 |
0.05~0.15 |
Max 0.5 |
0.30~0.61 |
0.025 |
0.80~1.25 |
0.44~0.65 |
– |
– |
– |
T22 |
0.05~0.15 |
Max 0.5 |
0.30~0.60 |
0.025 |
1.90~2.60 |
0.87~1.13 |
– |
– |
– |
T91 |
0.07~0.14 |
0.20~0.50 |
0.30~0.60 |
0.02 |
8.0~9.5 |
0.85~1.05 |
0.4 |
0.18~0.25 |
0.015 |
T92 |
0.07~0.13 |
Max 0.5 |
0.30~0.60 |
0.02 |
8.5~9.5 |
0.30~0.60 |
0.4 |
0.15~0.25 |
0.015 |
Grade |
Chemical Composition% |
Mechanical Properties |
|||||||
W |
B |
Nb |
N |
T. S |
Y. P |
Elongation |
Hardness |
||
T2 |
– |
– |
– |
– |
≥ 415MPa |
≥ 205MPa |
≥ 30% |
163HBW(85HRB) |
|
T11 |
– |
– |
– |
– |
≥ 415MPa |
≥ 205MPa |
≥ 30% |
163HBW(85HRB) |
|
T12 |
– |
– |
– |
– |
≥ 415MPa |
≥ 220MPa |
≥ 30% |
163HBW(85HRB) |
|
T22 |
– |
– |
– |
– |
≥ 415MPa |
≥ 205MPa |
≥ 30% |
163HBW(85HRB) |
|
T91 |
– |
– |
0.06~0.10 |
0.03~0.07 |
≥ 585MPa |
≥ 415MPa |
≥ 20% |
250HBW(25HRB) |
|
T92 |
1.50~2.00 |
0.001~0.006 |
0.04~0.09 |
0.03~0.07 |
≥ 620MPa |
≥ 440MPa |
≥ 20% |
250HBW(25HRB) |
|
ASTM A213/ASME SA213 T2, T11, T12, T22, T91, T92 Tolerance
Outside Diameter |
OD Tolerance |
WT Tolerance |
Ovality Tolerance |
Cut Length Tolerance |
OD≤ 12, 7 mm |
± 0, 13 mm |
± 15 % |
– |
+ 3, 18 mm, – 0 mm |
12, 7 mm < OD ≤ 38, 1 mm |
± 0, 13 mm |
± 10 % |
max, 1, 65 mm |
+ 3, 18 mm, – 0 mm |
38, 1 mm < OD ≤ 88, 9 mm |
± 0, 25 mm |
± 10 % |
max, 2, 41 mm |
+ 4, 76 mm, – 0 mm |
-
T11 Alloy Steel Tube for power generation, petroleum, and other high temperature services
-
T22 Alloy Steel Tube for power generation, petroleum, and other high temperature services
-
T5 Alloy Steel Tube for petroleum
-
T9 Alloy Steel Tube for petroleum
-
T91 Alloy Steel Tube for power generation
-
T92 Alloy Steel Tube for power generation
-
T1 Alloy Steel Tube for boiler replacement and repair
-
SA209 T1 tube for Manufacturing Boilers
-
ASTM A213/ ASME SA213 T5 Alloy Steel Tube for Superheaters
-
ASTM A213/ ASME SA213 T5 Alloy Steel Tube for Heat Exchangers
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: Is it OK to print my logo on products?A: Yes. OEM and ODM are available for us.
Q: How to ensure the quality?
A:Mill Test Certificate is supplied with shipment. If needed, a Third Party Inspection is acceptable or SGS
