P22 Grade Astm A355 Boiler Seamless Steel Pipe 20mng
P22 Grade Astm A355 Seamless High Pressure Boiler Steel Pipe 20MnG
about us:
Hebei Hongcheng Pipe Industry Co., Ltd. was established in 1992 and is located in the Development Zone of Yanshan County, Hebei Province. We are one of the largest steel product manufacturers on the coast of the Bohai Sea. A three-dimensional comprehensive transportation network has been formed. Our geographical position is superior and the transportation is very convenient.
We are one of the biggest manufacturer for steel products with a 80, 000-square-meter workshop,covers an area more than 120,000 square meters in size ,and well over 50 million USD in assets.our main products including stainless steel pipe ,stainless steel plate,stainless steel bar,seamless steel pipe ,low temperature steel pipe ,alloy steel pipe ,boiler pipe ,carbon steel plate ,alloy steel plate ,pipe fitting,copper products,titanium products and nickel
We warmly welcome and looking forward to have a nice cooperation with company both at home and at abroad.
Astm A355 Grade P22 Chrome Molybdenum Alloy Steel Seamless Pipe 16mo3 Alloy Steel Pipe Astm A335 P22 for Oil and Gas Production Line Seamless steel pipe is a steel pipe made from a single piece of metal without joints on its surface. According to the production method, seamless pipes are divided into hot-rolled pipes, cold-rolled pipes, cold-drawn pipes, extruded pipes, and pipe jacking. According to the cross-sectional shape, seamless steel pipes can be divided into two types: round and special-shaped. Shaped tubes come in many complex shapes, such as square, oval, triangle, hexagon, melon seed tube, star tube and finned tube. The maximum diameter is 650mm and the minimum diameter is 0.3mm. Depending on the application, there are thick-walled and thin-walled tubes. Seamless steel pipes are mainly used in petroleum geological drill pipes, cracked pipes in the petrochemical industry, boiler pipes, bearing pipes and high-precision structural steel pipes for automobiles, tractors and aviation.
| Product name | Material | Standard | Size(mm) | Application |
|
Low temperature tube |
16MnDG 10MnDG 09DG 09Mn2VDG 06Ni3MoDG ASTM A333 |
GB/T18984-2003 ASTM A333 |
OD:8-1240* WT:1-200 |
Apply to - 45 ℃ ~ 195 ℃ low temperature pressure vessel and low temperature heat exchanger pipe |
|
High-pressure boiler tube |
20G ASTMA106B ASTMA210A ST45.8-III |
GB5310-1995 ASTM SA106 ASTM SA210 DIN17175-79 |
OD:8-1240* WT:1-200 |
Suitable for manufacturing high pressure boiler tube, header, steam pipe, etc |
| Petroleum cracking tube |
10 20 |
GB9948-2006 |
OD: 8-630* WT:1-60 |
Used in oil refinery furnace tube, heat exchanger tube |
|
Low medium pressure boiler tube |
10# 20# 16Mn,Q345 |
GB3087-2008 |
OD:8-1240* WT:1-200 |
Suitable for manufacturing various structure of low and medium pressure boiler and locomotive boiler |
|
General structure of the tube |
10#,20#,45#,27SiMn ASTM A53A,B 16Mn,Q345 |
GB/T8162- 2008 GB/T17396- 1998 ASTM A53 |
OD:8-1240* WT:1-200 |
Apply to the general structure, engineering support, mechanical processing, etc |
|
Oil casing |
J55,K55,N80,L80 C90,C95,P110 |
API SPEC 5CT ISO11960 |
OD:60-508* WT:4.24-16.13 |
Used for extraction of oil or gas in oil Wells casing, used in oil and gas well sidewall |
Mechanical Property:
| Standard | Grade | Tensile Strength(MPa) | Yield Strength(MPa) | Elongation(%) | |
| ≤16 | >16-30mm | ||||
| GB/T8162-1999 | 10 | 335 | 205 | 195 | 24 |
| 20 | 390 | 245 | 235 | 20 | |
| 35 | 510 | 305 | 295 | 17 | |
| 45 | 590 | 335 | 325 | 14 | |
| 16Mn | 490 | 325 | 315 | 21 | |
| GB/T8163 | 10 | 335~475 | ≥205 | ≥24 | |
| 20 | 410~550 | ≥245 | ≥20 | ||
| Q345 | 490~665 | ≥325 | ≥21 | ||
| GB/T3087 | 10 | 333-475 | ≥196 | ≥24 | |
| 20 | 392-588 | ≥245/226 | ≥20 | ||
| GB/T5310 | 20G | 410-550 | ≥245 | ≥24 | |
| 12CrMoG | 410-560 | ≥205 | ≥21 | ||
| 15CrMoG | 450-640 | ≥235 | ≥21 | ||
| 12Cr1MoVG | 470-640 | ≥255 | ≥21 | ||
| GB/T9948 | 10 | 330-490 | ≥205 | ≥24 | |
| 20 | 410-550 | ≥245 | ≥21 | ||
| 12CrMoG | 410-560 | ≥205 | ≥21 | ||
| 15CrMoG | 410-640 | ≥235 | ≥21 | ||
| GB/T6479 | 10 | 330-490 | ≥205 | ≥24 | |
| 20 | 410-500 | ≥245 | ≥21 | ||
| 12CrMo | 410-560 | ≥205 | ≥21 | ||
| 15CrMo | 440-640 | ≥235 | ≥21 | ||
| Item | C | Si | Mn | P | S | Cr | Mo |
| P1 | 0.10-0.20 | 0.10-0.50 | 0.3-0.80 | ≤0.025 | ≤0.025 | / | 0.44-0.65 |
| P2 | 0.10-0.20 | 0.10-0.30 | 0.3-0.61 | ≤0.025 | ≤0.025 | 0.5-0.81 | 0.44-0.65 |
| P5 | ≤0.15 | ≤0.50 | 0.3-0.60 | ≤0.025 | ≤0.025 | 4.0-6.0 | 0.44-0.65 |
| P9 | ≤0.15 | ≤0.50 | 0.3-0.60 | ≤0.030 | ≤0.030 | 8.0-10.0 | 0.90-1.10 |
| P11 | 0.05-0.15 | 0.5-1.0 | 0.3-0.60 | ≤0.025 | ≤0.025 | 1.0-1.50 | 0.44-0.65 |
| P22 | 0.05-0.15 | ≤0.50 | 0.3-0.60 | ≤0.025 | ≤0.025 | 1.9-2.60 | 0.87-1.13 |
| P21 | 0.05-0.15 | ≤0.50 | 0.3-0.60 | ≤0.025 | ≤0.025 | 2.65-3.35 | 0.80-1.06 |
| P91 | 0.08-0.12 | 0.20-0.50 | 0.30-0.60 | ≤0.020 | ≤0.010 | 8.0-9.5 | 0.85-1.05 |
| P15 | 0.05-0.15 | 1.15-1.65 | 0.30-0.60 | ≤0.025 | ≤0.025 | / | 0.44-0.65 |
FAQ
1.Q:Are you a factory or trading company?
A: We are a factory, has more than 20 years experience in pipe fittings production.
2.Q:Where is your factory located? How can I visit there?
A: Our factory is located in cangzhou City, hebei Province,China.
3.Q:How does your factory do regarding quality control?
A: We are ISO9001& PED certified by TUV. We serious control the quality from raw material to finished pipe fittings. So that we can 100% sure our goods is qualified.
4. Q: Price high ?
A: Our price is workable. We had tried use auto equipment to save Workers cost, and control other costs. like human sources, logistics etc.
5.Q: After sales service.
A: Quality are promised. If our products are not meet the contract we would like to send free goods to you.
