servo motor M12 Cable Connector IP67 with PUR 2m 12A Power Cable
M12 S Code connector 2+PE 3pin male un-shielded molded PUR 2m 12A power cable,free end
M12 S-Coding 3Pin(2+PE) or 4Pin (3+PE) Cable Connectors with 12mm thread locking mechanism, rated IP67 protection degree, contacts configuration covers pins of 4-poles, Compliant with IEC 61076-2-111 and mainly designed for servo motor's power transmission.
● IP67, IP68, IP69K and UL approvals
● 360° EMI-Shielded or non-shielded versions are available
● 2, 3, 4, 5, 6, 8, 12, 17 poles are available
● TPU over molded and PA+GF or metal shell
● Anti-vibration locking screw design
● Operating voltage 630V/250V/60V/48V/30V;
● Current range: 20A,16A,12A,8A,4A,2A,1.5A
● Customized cable length, with PUR,PVC,LSZH,EtherNet,Profinet.
Railway NFPA130,NMEA 2000,DeviceNet,CAN,Profibus,CC-Link cable options
● Gold-plated solid brass or phosphor bronze contacts ≥ 600 times mating life
● Durable cable material suitable for Drag Chain moving and bending demands
● Good stripping and terminating properties
● Sturdy metal coupling screws with anti-vibration design, 48 hours Salt Spray Test
● UV Resistant, Hydrolysis Resistant,Oil resistant
● Temperature Range: Dynamic -25 ~ 80℃, Static: -40 ~ 80℃.
● Protection degree: IP67 in locked status, IP68 base on customer specific requirements.
● RoHS, REACH compliant.
