● Tailor made material to meet various application conditions
● Gold-plated solid brass or phosphor bronze contacts ≥ 600 times mating life
● Durable cable material suitable for Drag Chain moving and bending demands
● Good stripping and terminating properties
● Sturdy metal coupling screws with anti-vibration design, 48 hours Salt Spray Test
● UV Resistant, Hydrolysis Resistant,Oil resistant
● Temperature Range: Dynamic -25 ~ 80℃, Static: -40 ~ 80℃.
● Protection degree: IP67 in locked status, IP68 base on customer specific requirements.
● RoHS, REACH compliant.

FAQ

● What is DeviceNet connector?

DeviceNet is an ODVA device-level communication protocol for industrial automation. DeviceNet cables offer an open, low-cost system that link between industrial devices such as sensors and actuators and higher-level devices such as programmable logic controllers and PCs.

● What does the coding mean on M12 connectors?

This coding prevents incorrect mating on products. In addition, shielding is available in most coded M12 connectors. For example, X-coded connectors are specifically shielded by the design of their coding.

● What is the difference between DeviceNet and Ethernet?

DeviceNet also has the advantage that it is uses CIP exactly as EtherNet/IP does, only over a CAN physical layer. Instead of the TCP/IP stack and Ethernet physical layer, DeviceNet uses CAN.Simpler, more cost-effective components (but more expensive cabling than Ethernet)
