Ethernet Cat 7 RJ45 Patch Cord Green PUR Male Plug For Surveillance Cameras
|
Connector Technical Data
|
|||||||||
|
Model Number
|
RJ7C5LI24CG03 | ||||||||
|
Connectors No.
|
8P8C | ||||||||
| Termination | Insulation Percing Contect | ||||||||
| Rated current | 1.5A | ||||||||
|
Rated Voltage
|
30V
|
||||||||
|
Impulse Voltage
|
1000V Contact to Contact, 1500 Contact to Screen
|
||||||||
| Characteristic impeance | 100Ω | ||||||||
| Contact carrier | PC | ||||||||
| Contect | Brass Gold plated | ||||||||
| Connector overmolding | PVC, TPU | ||||||||
| Reference Standard | IEC 60603 7 7 | ||||||||
Cat7 S/FTP jumper is a high-quality Cat7 cable. These cables are suitable for connecting computers, hubs, switches, print servers
and wiring racks, but are found to be increasingly used in audio and video applications and surveillance cameras. Cable materials
consist of thermoplastic compounds that emit limited smoke and halogen-free when exposed to high-calorie sources. Gold-plated
contacts help to obtain the best electrical conductivity, as well as stain and corrosion resistance. This improves signal
integrity and overall performance and lifetime of cables.
Application
Suitable for connecting computers, hubs, switches, print servers and wiring racks, but found more and more use in audio and video
applications and surveillance cameras.
FAQ
● What is the difference between Cat6 and Cat7 cables?
The cat7 cable comes with better shielding on individual wire pairs than the cat6 cable. The shielding on each pair of wires helps to reduce crosstalk and noise. A standard cat6 cable offers a performance of up to 250 Mhz, while a cat6a cable can transmit up to 500 Mhz. The maximum cabling length of a cat6 cable is 100 meters.
