Railway Transit RJ45 Patch Cord 8P8C Green PVC Male AWG 26 Plug Rj45 Socket Cable
Price:
Negotiated
MOQ:
100
Delivery Time:
2~3 weeks
Brand:
CABLEFORCE
Product Description
Railway Transit Cables RJ45 Patch Cord 8P8C Green PVC Male AWG 26 Plug
|
Connector Technical Data
|
|||||||||
|
Model Number
|
RJ5EC3LI26RB10 | ||||||||
|
Connectors No.
|
RJ45 8P8C | ||||||||
| Termination | Insulation Percing Contect | ||||||||
| Rated current | 1.5A | ||||||||
|
Rated Voltage
|
30V
|
||||||||
|
Impulse Voltage
|
1000V Contact to Contact, 1500 Contact to Screen
|
||||||||
| Cable Specification | AWG 26, AWG 24 | ||||||||
| Contact carrier | PC | ||||||||
| Contact | Phosphor Bronze, Gold Plated | ||||||||
| Connector overmolding | PVC, TPU | ||||||||
About Us
CABLEFORCE globally offers a wide variety of industrial connectors and cable connectivity solutions to meet either standard or harsh environment signal and power transmission application. Its wide range of metric circular connectors and cable assembly that fit almost any standard sensor or actuator application and includes features such as accurate IP ratings, a wide range of cable jackets, and multiple contacts pin configurations, and high quality rugged materials.
Cable Characteristics (differences noted):
RJ45, CAT 5E, CAT 6A, CAT 7 Ethernet cables
USB 2.0, USB 3.0 data cable
D-Sub, VGA monitoring conneting cable
LSZH Fire retardant
360° EMC / EMI Shielded
Customized cable specification with single or double ended cord set
FAQ
●What is a RJ45 socket?
The eight pin design gives the RJ45 socket its wider appearance. It also increases the capacity for data transmissions. This is why this type of wall socket is used primarily for Ethernet and high speed Internet connections. When a telecommunications company receives an order for data lines, it will almost always install some type of RJ45 jack or socket.
