CAT 6A Industrial Ethernet Cable M12 Female To Rj45 Cable For Safety Light Grids
|
Connector Technical Data
|
|||||||||
| Model Number | MC08C4LSXSB26CG30C6A | ||||||||
| Contact No | 8 pin | ||||||||
| Coding |
X code
|
||||||||
| Contact Resistance | ≤5mΩ | ||||||||
|
Characteristic Impedance
|
100Ω ±15
|
||||||||
|
Wire Gauge
|
0.14mm²(AWG 26) CAT 6A
|
||||||||
|
Type
|
Profinet Industrial Ethernet Cable
|
||||||||
|
Contact Carrier
|
TPU+GF
|
||||||||
|
Screw Nut
|
Brass CNC Nickel plated
|
||||||||
|
Contact
|
Phosphor bronze | ||||||||
|
Protection Degree
|
IP67,IP68
|
||||||||
Manufacturing environments, where PROFINET is most commonly used, are characterized by having challenging environmental conditions. In that environment, standard Ethernet cables, like those you find in your office or home, might break or damage easily. Extreme temperatures, moisture, vibrations, electro magnetic interference, and many other factors contribute to the deterioration of cables.
Due to the challenging environment meant, industrial Ethernet cables are a common choice in automation facilities. On the wire, Industrial Ethernet is just Ethernet. Yet, Industrial Ethernet is characterized by rugged hardware, and its wiring is protected with shielding and jacketing.
● IP65 IP67 IP68 and UL approvals
● 8P poles are available
● TPU over molded and PA+GF or metal shell
● Anti vibrating locking screw desigh
● Operating voltage: 630V, 250V, 60V, 48V, 30V
● Current rating: 20A, 16A, 12A, 8A, 4A, 2A, 1.5A
FAQ
● What are the advantages of PROFINET?
PROFINET offers the option for wireless transmission over WiFi and Bluetooth. Using standard Ethernet components such as switches, cables, or connectors in PROFINET networks is advantageous. Utilizing Ethernet cables in PROFINET projects is a huge benefit, as they are ubiquitous, affordable, and versatile.
● What is difference between PROFIBUS and Ethernet?
PROFINET is a fieldbus system which is based on Ethernet. PROFINET is one of the many industrial ethernet systems out there, which is often compared to PROFIBUS. PROFINET is a full duplex system. Because it's ethernet based, PROFINET can operate on a much higher transmission speed than PROFIBUS.
●Do I need PROFINET If I already have Ethernet?
On the wire, they are the same thing. Yet, industrial Ethernet is characterized by ruggedized hardware, shielding protection, and proper jacketing. Do I need PROFINET if I already have Ethernet in an automation network? Yes, you still need PROFINET. You create a connection if you link two nodes in a network with an Ethernet cable.
