Full HD 40 Points Embedded Touch Monitor 100-240VAC 43 Inch Touchscreen Monitor
iTAYFT 43 Inch Full HD Resolution 40 Touch Points Embedded Touch Monitor
1. Product Description
iTAYFT’s Multi-Touch Panel Mount LCD Monitors feature Projected Capacitive (PCAP) touch screen, the same technology found in smart phones and tablets but equipped for your industrial application. Our Multi-Touch Panel Mount LCDs come in many sizes and easily integrates into your enclosure, cabinet, console, wall, kiosks or other applications.
Using Projected Capacitive touchscreen technology (PCAP) allows for a modern user interface thereby making use of new and extended ways of user input and control. Gesture-based interactions by touching and pointing, with one finger or more, rotate, pinch to zoom and move objects on the display.
2. Technical Datasheet
2.1 LCD
| Size | 43" TFT LCD | ||||
| Maximum Resolution | 1920 x 1080 | ||||
| Contrast Ratio | 1100:1 | ||||
| Brightness (Backlight Type) | 450 nits (No Touch), 351 nits (Projected Capacitive) | ||||
| View Angle | H:178°, V:178° | ||||
2.2 Touch Spec.
| Touch Screen | Projected Capacitive | ||||
| Touch Points | 40 | ||||
| Touch Screen Interface |
USD-HID (Type B)
|
||||
2.3 IO Ports
| Serial Port | 1 x RJ-11 (for Optional Remote Key) | |||||||||||
| USB Port | 1 x USB 2.0 (Type B) for Touch Interface (USB-HID) | |||||||||||
| Video Port | 1 x VGA, 1 x HDMI, 1 x DVI, 1 x DP | |||||||||||
| Audio Port | 1 x Line-in | |||||||||||
| Power Input | 1 x AC Inlet | |||||||||||
2.4 Physical Properties
| Power Supply | AC Input 100~240Vac, 50/60Hz | |||||||||||
| Speaker | 2 x 12W | |||||||||||
| Housing Color | Black | |||||||||||
| Material | Glass, AL, Plastic (ABS) | |||||||||||
| Compliance | - | |||||||||||
| Dimensions (W x H x D) mm | 983.2 x 571.4 x 80.7 | |||||||||||
| Net Weight (kg) | 19.5 Kg | |||||||||||
| Gross Weight (kg) | 25.0 Kg | |||||||||||
| Carton (W x H x D) mm | 1170 x 745 x 200 | |||||||||||
| VESA | 400 x 400 mm | |||||||||||
| Certifications | CE, FCC, UL, cUL, CCC, RCM, RoHS | |||||||||||
2.5 Environment Requirement
| Operating Temperature | 0°C ~ 40°C, RH. Non-Condensing | ||||
| Storage Temperature | -20°C ~ 60°C, RH. Non-Condensing | ||||
3. Drawing
4. Apllications
Industrial field,
Retail, Signal signage,
Medical field,
Financial,
Check-in, etc.
