Non Woven 4 Color Flexo Printing Machine (Central Drum Type) 200m/Min,4 Color Non Woven Flexo Printing Machine 8 Colors
200m/Min 4 Color Flexographic Printing Machine (Central drum type) 1/5 Central Drum 8 Colors Price Taiwan Roll To Roll F
200m/Min 4 Color Flexographic Printing Machine (Central drum type)
Feature:
1.After mounting the plate and registration, no longer need registration, improve yield;
2.Replacing 1 set of Plate Roller (unloaded 6pcs old roller, installed six new roller after tightening), only 20 Minute registration can be done by printing;
3.The machine first mount plate, pre-trapping function, to be completed in advance prepress trapping in the shortest possible time.
4.Maximum production machine speed up 200m/min, registration accuracy ±0.15mm.
5.The overlay accuracy does not change during lifting running speed up or down.
6.With precision structural, easy operation, easy maintenance, high degree of automation and so on, one person can operate.
7.China famous Inovance brand Servo motor for unwinding and rewind.
Technical Parameter :
| Model | CI4-600 | CI4-800 | CI4-1000 | CI4-1200 | CI4-1400 | CI4-1600 |
| Max. Material width | 650mm | 850mm | 1050mm | 1250mm | 1450mm | 1650mm |
| Max. Printing width | 560mm | 760mm | 960mm | 1160mm | 1360mm | 1560mm |
| Printing color | 4+0 | |||||
| Printing length | 11.8''-31.4''(300-800mm) | |||||
| Printing cylinder way | Hydraulic control up and down | |||||
| Drive type | Big center Roller drive | |||||
| Mechanical speed | 200m/min | |||||
| Printing speed | 10-180m/min | |||||
| Anilox roller | Ceramic anilox roller 4pcs: Shanghai murata brand 200-800LPI Chamber doctor blade 4pcs with two diaphragm pump |
|||||
| Tension system | Automatic tension controller with magnetic | |||||
| EPC | Web guide 1pcs | |||||
| Register precision | Longitudinal:±0.1mm crosswise:±0.1mm; | |||||
| Color register | By motorized ( left and right, up and down) | |||||
| Unwind/rewind dia. | Φ1000mm/Φ1200mm | |||||
| Unwind/rewind way | Center unwind; Servo motor for rewind ; | |||||
| Material holder | Air shaft 3'', 2pcs | |||||
| Dry system | Electric heating | |||||
| PLC human touch screen | 1set, China famous Inovance brand | |||||
| Image inspect system | 1set, China famous kesai branad | |||||
| Machine power | 45KW | 50KW | 55KW | 60KW | 70KW | 80kw |
| Machine size (L x W x H) |
8×2.2×3.5m | 8×2.4×3.5m | 8×2.6×3.5m | 8×2.8×3.5m | 8×3×3.5m | 8×3.2×3.5m |
Machine Also can made as client requirement. .
Different printing material , machine some parts design different. Pls kindly show Printing material when inquiry.
Optional parts: need extra cost
1. Various size of printing cylinder
2. chamber doctor blade
3. Tur bar: Half width-double sides printing device
4. Color register: by motorized ( left and right, up and down)
5. Double unwinder /rewinder system
6. Automatic loading
7. Automatic unloading
8. shaftless for unwind
9. Servo motor for unwind/rewind
10. crane
11. plate mounting machine
12. ultrasonic anilox roller cleaning machine
a professional Of Kinds Printing Machines and related products .
We Have Many Kinds Printing Machines, Normal Speed Printing Machine 50 meter/min , Middle Speed 80Meter/min and higher speed Printing Machine which Over 120M/MIN, 160M/MIN, 200M/MIN
Machine size: Standard size: 600-1200mm
also we can make 1500mm, 1800m,2000mm, 2400mm , 3200mm .
Offer your details , Make machines only belongs to you .
1) Good Quality , Well and timely Service, Competitive Price
2) Certificate : CE Certificate
3) One Year Warranty For Free, Long Life Service .
4) Tension Controller, EPC ,Ceramic Rollers,Doctor Blade.
5)Taiwan Motors
Our Service :
1 Year Guarantee !
100% Good Quality !
24 Hours online Service!
I'V never believe We are the best, But I will try to be the best for you
if you have any query, pls tell me freely. We will try our best to satisfy with you !
Toolbox 1pcs: spare part for free
| 1 | Tool box | 1set |
| 2 | Phillip screwdriver | 1pcs |
| 3 | Slotted screwdriver | 1pcs |
| 4 | Inner Hexgam Spanner | 1set |
| 5 |
Oil gun
|
