A36 Hot Rolled Carbon Steel Rods ASTM A576 Cold Drawn

ASTM A576 Cold Drawn 1045 Mild Steel Round Bar For CNC Mills

Carbon Steel Bars Introduction

The properties of carbon steel are high hardness, strength, wear resistance and anti-corrosion.

Carbon steel is an alloy with carbon and iron, with carbon content up to 2.1% by weight. The increase in the carbon percentage will raise steel’s hardness and strength, but it will be less ductile. Carbon steel has good properties in hardness and strength, and it is less expensive than other steels.

Carbon steel bar is a kind of general-purpose steel bar that offers excellent formability and weldability, being used in a wide variety of applications including auto manufacturing, shipbuilding, aerospace industry, petrochemical plants, auto-power and wind-engine, metallurgical machinery, precision tools, etc.

- Auto manufacturing
- Aerospace industry
- Auto-power and wind-engine
- Metallurgical machinery

ASTM A36 hot Rolled mild steel bars are used for general purpose applications. This steel is a low carbon grade, having good over-all mechanical properties. It is easy to fabricate by the usual structural methods, such as cold and hot forming and welding. It is easy to fabricate by the usual structural methods, such as mild cold and hot forming and welding.

Application:

This material is used for general purpose structural and miscellaneous non-critical applications that involve mild cold bending, mild hot forming, punching, and welding. Such applications include parts for general machinery, agricultural implements, transportations equipment, etc. It is used where seams and other surface imperfection may be tolerated.

WHAT IS COLD DRAWN STEEL BAR?

Cold drawing hot rolled bars is accomplished by pulling (drawing) a bar through a mould which is smaller than the incoming hot rolled size.

THE PROCESS OF COLD DRAWING STEEL BARS

The “cold working” process improves the dimensional tolerances of the bar, the straightness, and the surface appearance and enhances the physical properties of the steel. All our steel cold drawn bars are also produced with our in line proprietary surface inspection equipment. Machinability and improved chip formation are enhanced by the elevated physical properties.

BENEFITS

• Improved dimensional tolerances
• Improved straightness capability
• Minimizes stock removal improving equipment performance and tool life
• 100% surface inspected to ASTM A-108 or better tolerances
• Improved mechanical properties aiding machinability and strength for applications
• Available in round, square, hexagon and profile shapes

TYPICAL OPERATIONS AND APPLICATIONS USING COLD DRAWN BARS

The below are a few of the many applications using cold drawn bars for their raw material:

• Screw machines
• CNC lathes
• CNC mills
• Rotary transfer machining
• Hydraulic fittings
• Gears
• Bushings
• Fasteners
• Cylinders
• Pipe fittings

Carbon Steel Round Bars Parameter
