0.2mm Stainless Steel Coils
0.2mm thickness 2B finish cold rolled 304 304l 310 316 316l thin stainless steel coils made in China
Stainless steel coil is also known as stainless steel belt and stainless steel coil, characterized by complete specifications, diverse materials; High dimensional accuracy, up to ± 0.1mm;Excellent surface quality, good brightness; Strong corrosion resistance, high tensile strength and fatigue strength; Stable chemical composition, pure steel, low inclusion content, widely used in construction, shipbuilding, vehicle manufacturing, machinery manufacturing, furniture and household appliances industry, electrical and automation industry.
300 Series stainless steels are classified as austenitic, and are hardenable only by cold working methods. These grades of stainless have chromium (approx. 18 to 30%) and nickel (approx. 6 to 20%) as their major alloying additions. Type 304 is the most widely used alloy of all stainless steels. 300 Series Stainless steel alloys resist corrosion, maintain their strength at high temperatures and are easy to maintain.
Stainless Steel 304 coils contain a minimum of 18% chromium and 8% nickel. These coils also contain carbon which makes the ASTM A240 SS304 one of the most versatile materials for use in a lot of varied industries. These SS 304 coils also provide high ease of fabrication and first-rate formability. Available in a wide array of forms and finishes, these coils are suitable for work at both indoor and outdoor conditions. From mechanically brushed finishes to mill finishes, stainless steel 304 coils are also available in textures finishes. High Corrosion resistance and Oxidation resistance makes these coils applicable under deep-drawn marine conditions. The ASTM A240 SS 304 coils can resist Oxidation in infrequent service up to 870°C and 925°C in Continuous service. An Effective price point of these coils makes them favorable for standard use.
Stainless steel SS304 has application in different industries. They are used in making sinks an splashbacks. They are also used in making cookware as they provide an antibacterial surface. Marine Environment applications are well suited for SS 304 DIN 1.4301 coils. The coils are also used in the manufacturing of Food Processing Units, Dairy and also Breweries. The SS 304 coils are also used in the manufacturing of a lot of Medical appliances.
Specification
Stainless Steel 304 Coils Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 304 | 1.4301 | S30400 | SUS 304 | 304S31 | 08Х18Н10 | Z7CN18‐09 | X5CrNi18-10 |
Stainless Steel 304 Coils Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | - | 8 – 11 | - |
SS 304 Coils Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
- Stainless Steel Coil with wooden pallets, standard export packing or as required
20ft GP: 5898mm(Length)x2352mm(Width)x2393mm(High), Max. 26 Ton
40ft GP: 12032mm(Length)x2352mm(Width)x2393mm(High), Max. 26 Ton
40ft HC: 12032mm(Lengh)x2352mm(Width)x2698mm(High), Max. 26 Ton
- Qingdao,Tianjin,Shanghai Port
Available Types of 304 SS Coils
Stainless Steel 304 Coil | SS TP304 Coils | Stainless Steel 304 HR Coil | SUS 304 Coils | SS TP304Cold Rolled Coil | 304 SS Hot Rolled Coils | UNS S30400 Coils | SS DIN 1.3041 Coils | TP304 Stainless Steel CR Coils | SS 304 2D Finish Coils | 304 Stainless Steel BA Finish Coils | SS 304 jindal Coils | SS 304 jindal Strips | SS 304 Matt PVC Coils | Stainless Steel 304L Industrial Coils | ASTM A240 SS 304 Coils | AISI 304 Steel Flat Strips | ASME SA240 Stainless Steel 304 Coil.
304 Stainless Steel Coils Applicatoin
- √304 Stainless Steel Coil Used in Tractor
- √304 Stainless Steel Coil Used in Automotive Trim
- √304 Stainless Steel Coil Used in Stamped Machined Products
- √304 Stainless Steel Coil Used in Cookware
- √304 Stainless Steel Coil Used in Appliances
- √304 Stainless Steel Coil Used in Kitchen
- √304 Stainless Steel Coil Used in Foodservice Equipment
- √304 Stainless Steel Coil Used in Sinks
- √304 Stainless Steel Coil Used in Railway Cars
- √304 Stainless Steel Coil Used in Trailers
