60V 30Ah 1800Wh LiFePO4 Battery Packs For 250W 2500W Ebike Scooter
60V 30Ah 1800Wh LiFePO4 Battery Packs For 250W 2500W Ebike Scooter
60V 30Ah LiFePO4 Battery Packs 1800Wh 50A BMS For 250W-2500W Ebike Scooter
LiFePO4 Battery Packs Quick details :
1. Diameter*Height : 35.1x13.1x7.5cm ( Lithium Ion 21700 size 19S4P )
2. Nominal Voltage : 60V
3. Nominal Capacity : 30Ah 1800Wh
4. Cycle life : 5000 cycles
5. Standard charging ways : CC / CV
6. Li-ion / Lithium Ion rechargeable LiFePO4 battery cell
7. CE , UL ,UN38.3 , MSDS compliant
Ebike Scooter Battery Description :
36V 20AH Electric Bicycle/Ebike Battery, with 42V 2A fast Charger, 50A BMS Protection Board, T-plug/XT60 Connector and Battery Level Light,fit for 500W/350W/300W/250W/200W Bike Motor/Scooters.
LiFePO4 material is safer than LiCoO2 & LiMn2O4 for its stable structure can be kept very well under continuous charging & discharging situations.Longer than 5000 cycle life is more suitable for application use.
Top A grade cells and built-in a 50A BMS (Battery Management System) prevent over-charge, over-discharge, over-current and short circuit and ensure the long life expectancy. Each pack have ran through a full charge and discharge test in produce, make sure you getting every amp hour you paid for.
High cell density,More capacity.The capacity of the battery after 800-1000 cycles is ≥80%,and the life span is 3 times that of lead-acid batteries.Using this lithium battery 72v means that you don't need to replace the battery for 3-5 years.
This battery's made from lithium ion that keeps a charge and keeps its shelf life longer than lithium iron batteries that tend to die out quickly. The outermost PVC material prevents rain from damaging the battery. Li-ion battery still has a capacity of more than 80% after 1000 cycles.
LiFePO4 Battery weighs only 47.4 lbs for one module, only 1/3 the weight of lead acid batteries, which makes it an easy choice for RVs, Marine and Off-Grid Applications when mounting or mobility is in the consideration.
We can also customize any size and function you need.Such as 12V/24V/36v/48v/60V/72v 20AH, 50AH,100h, 120ah, 150ah,200ah, 300ah, 400ah, 800ah etc..
LiFePO4 Battery Packs Specifications :
| NO | Items | Specification | Remarks | |
| 1 | Nominal Capacity | 30Ah | 0.2C Discharge | |
| 0.2C Discharge | ||||
| 2 | Nominal Voltage/shipping voltage | 60V | Voltage | |
| 3 | Discharge Cut-off Voltage | 56V | 0.2C Discharge | |
| 0.2C Discharge | ||||
| 4 | Charge Limited Voltage | 66V | 0℃～45℃ | |
| 5 | Standard Charge Current | 20A | 0℃～45℃ | |
| 6 | Standard Discharge Current | 20A | -20℃~ +60℃ | |
| 7 | Rapid Charge Current | 0.5C 20A | 10℃～45℃ | |
| 8 | Rapid Discharge Current | 0.5C 20A | -20℃~ +60℃ | |
| 9 | Max. Charge Current | 1C 35A | ||
| Max Pulse Current | 3C | |||
| 10 | Internal Impedance | ≤10mΩ | AC 1kHz condition | |
| At AC 1kHz | ||||
| 11 | Weight | About 7.5kg | Weight 7500±20g | |
| 12 | Storage Temperature Range | ≤1 month | -20~ 45℃ | Factory Voltage 60~66V |
| ≤3 months | 0℃~ +30℃ | Ex-factory Voltage 60~66V | ||
| ≤12 months | 20±5℃ | |||
LiFePO4 Battery Packs Details :
LiFePO4 Battery Packs Applications :
Electric Bike: Compatible with ANCHEER/VELOWAVE(Measurement is required)
Electric Scooter
Electric Motorcycle
Electric Tricycle
Solar Panels
