China MC4 1000V DC T Branch Solar Panel Male Female Connectors Moistureproof for sale
China MC4 1000V DC T Branch Solar Panel Male Female Connectors Moistureproof for sale
China MC4 1000V DC T Branch Solar Panel Male Female Connectors Moistureproof for sale

MC4 1000V DC T Branch Solar Panel Male Female Connectors Moistureproof

Price Negotiable
Price: negotiation
MOQ: 500
Delivery Time: samples in 5 working day
Brand: SolarverTech
Product Description

T Branch Solar Connector



Product Description





Specification

Type
PV-LT6
Rated Voltage
1000V DC
Rated impulse voltage
8000V
Rated insulation voltage
6000V
Rated Current
30A
Pollution Degree
2
Protection Degree
IP67
Contact Resistance
≤0.5mΩ
Ambient Temperature
-40℃~+90℃
Flame Class
UL94 V-0
Insulation Material
PPO
Standard
IEC 62852

FAQ:

Q1:Where are the photovoltaic cables used ?
A1:Photovoltaic cables are used to connect solar cell modules and inverters.


Q2:How to choose the type and specification of photovoltaic cable ?
A2:Select UL4730 standard PV WIRE for the UL standard area; Select PV CABLE(or TUV 2 PfG 1169) from standard EN50618 for the EN standard area, The product models are PV Wire **AWG/h1z2z1-k**mm2(orpv1-f).
