G657a G652d Ftth Round Drop Cable With Messenger 12 Strand Outdoor Fiber Optic Cable
Price:
Can be negotiable
MOQ:
20,000 Meters
Delivery Time:
5-8Days
Brand:
JIANGHONG or OEM
Product Description
GJYXCH Optic Fiber Cable outdoor FTTH Drop Cable 12cores
DESCRIPTION
12cores Optic Fiber Cable Outdoor FTTH Drop Cable is to place the optical fiber in the center, place two parallel steel wires strength members on both sides, attach a suspension steel wire to the outer side of the cable, squeeze LSZH and PE sheath into cable.
FEATURES
Unique groove design, easy to strip and installation;
High strength Phosphor suspension wire have high tensile performance;
APPLICATIONS
Outdoor overhead
PERFORMANCE
| Type | Max.Attenuation | Tensile strength | Crush resistance | Min.Bending radius(Dynamic) | |||
| 1310nm | 1550nm | Short term | Long term | Short term | Long term | ||
| GJYXCH | 0.36dB/km | 0.25dB/km | 600N | 300N | 2200N | 1000N | 40mm |
