140lm/W Waterproof LED Street Light Dimmable from china manufacturer
LED Street Light 160lm/W 100-265V PF0.9 6500K Aluminium Led Lamp
The most important characteristic of LED for lighting is the function of directional light emission, because almost all power LED have reflectors, and the efficiency of these reflectors is obviously higher than the reflectors of lamps. In addition, the light effect detection of LED has included the efficiency of its own reflector. The road lamps using LED should make use of the directional emission characteristics of LED as far as possible, making each LED in the road lamps direct the light to each area of the road surface, and then using the auxiliary light distribution of the lamp reflector, to achieve a very reasonable road lighting integrated light. In the design of actual road lighting lamps, each LED can be fixed on the lamp with a spherical universal joint on the premise of basically setting the direction of each LED, when the lamp is used for different heights and illumination widths, the direction of each LED can be adjusted to achieve a satisfactory result.
1.Brand new innovation patent light design,the 11° deviation angle design for the portrait light curve,
which is the first one in the domestic,make more light towards to the middle of the road.
And the transversal light angle is 135°with the 0.65 regularity to avoid the dark area radically.
2.Innovated integration heat radiation light body,make utmost contact area to the air,
less joint seam between aluminum basilar plate and the heat radiation body,make the heat emanate quickly.
The structure temperature is around 45 ℃ which prolong the light working life,
3.Dimmable power driver is invented by Institute of electronic of Chinese Academy of Sciences,
which makes the light working life more than 5000hours.
| Parameter Informations | JMJX-30 | JMJX-60 | JMJX-90 | JMJX-120 | JMJX-150 |
| Rated Power | 30W | 60W | 90W | 120W | 150W |
| LED Chip | 3W/pc | 3W/pc | 3W/pc | 3W/pc | 3W/pc |
| LED Quantity | 24 | 48 | 72 | 96 | 120 |
| Color Temperature | 4500-5500K | 4500-5500K | 4500-5500K | 4500-5500K | 4500-5500K |
| Input Voltage | AC100-260V | AC100-260V | AC100-260V | AC100-260V | AC100-260V |
| Frequency Range | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz |
| Power Factor | >0.97 | >0.97 | >0.97 | >0.97 | >0.97 |
| LED Luminous Efficiency | 140lm/w | 140lm/w | 140lm/w | 140lm/w | 140lm/w |
| (%) Lamp's Efficiency |
>92% | >92% | >92% | >92% | >92% |
| IP Grade | IP65 | IP65 | IP65 | IP65 | IP65 |
| Working life | >80000HRS | >80000HRS | >80000HRS | >80000HRS | >80000HRS |
| Environment Temperature | -30℃to+65℃ | -30℃to+65℃ | -30℃to+65℃ | -30℃to+65℃ | -30℃to+65℃ |
| Light Body material | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium |
| Pole Height | 6m | 7m | 9m | 10m | 12m |
| Central Illumination | 40lux(6m) | 55lux(7m) | 48lux(9m) | 47lux(10m) | 40lux(12m) |
| Pole Distance | 25M | 35M | 40M | 45M | 50M |
| Installing Size | Φ61mm | Φ61mm | Φ61mm | Φ61mm | Φ61mm |
| Products Size | 520*380*120mm | 600*380*120mm | 720*380*120mm | 840*380*120mm | 960*380*120mm |
| Packing Size | 580*445*185mm | 660*445*185mm | 780*445*185mm | 900*445*185mm | 1020*445*185mm |
| Net Weight | 8KG | 10KG | 12KG | 14KG | 16KG |
| Gross Weight | 10KG | 12KG | 14KG | 16KG | 18KG |
