30W 40W 50W Led Street Light Yard Decorations Heat Radiation Light Body energy-saving lamps and LED
SMART LED STREET LIGHT Saving Energy Heat Radiation Light Body
1.Brand new innovation patent light design,the 11° deviation angle design for the portrait light curve,which is the first one in the domestic,make more light towards to the middle of the road.And the transversal light angle is 125°with the 0.65 regularity to avoid the dark area radically.
2.Innovated integration heat radiation light body,make utmost contact area to the air,
less joint seam between aluminum basilar plate and the heat radiation body,make the heat emanate quickly.
The structure temperature is around 45 ℃ which prolong the light working life,
3.Dimmable power driver is invented by Institute of electronic of Chinese Academy of Sciences,
which makes the light working life more than 4000hours.
4.High temperature safety illuminance protecting system:
In order to insure the LED street light working effciency and long life in the favourable working condition(within 55℃),
coursertech street lightswill switch into half power if the light exceed the standard temperature(65℃)
5.Dimmable time-delay power interruption system:the time-delay is used for the LED automatic control for Coursertech street lights,
which means after 6 hours(it can be adjusted according to the actual requirement),the light will switch into half power automatically,
to save the power while keep the basic brightness.
6.LED chip adopted is Germany Osram,American Bridgelux and Cree,reliable quality!
| Parameter /Item No. |
JMJX-30 | JMJX-60 | JMJX-90 | JMJX-120 | JMJX-150 |
| Rated Power | 30W | 60W | 90W | 120W | 150W |
| LED Chip | 3W/pc | 3W/pc | 3W/pc | 3W/pc | 3W/pc |
| LED Quantity | 24 | 48 | 72 | 96 | 120 |
| Color Temperature | 4500-5500K | 4500-5500K | 4500-5500K | 4500-5500K | 4500-5500K |
| Input Voltage | AC100-260V | AC100-260V | AC100-260V | AC100-260V | AC100-260V |
| Frequency Range | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz |
| Power Factor | >0.97 | >0.97 | >0.97 | >0.97 | >0.97 |
| LED Luminous Efficiency |
140lm/w | 140lm/w | 140lm/w | 140lm/w | 140lm/w |
Lamp's Efficiency |
>92% | >92% | >92% | >92% | >92% |
| IP Grade | IP65 | IP65 | IP65 | IP65 | IP65 |
| Working life | >80000HRS | >80000HRS | >80000HRS | >80000HRS | >80000HRS |
Environment Temperature |
-30℃to+65℃ | -30℃to+65℃ | -30℃to+65℃ | -30℃to+65℃ | -30℃to+65℃ |
| Light Body material | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium |
| Pole Height | 6m | 7m | 9m | 10m | 12m |
| Central Illumination | 40lux(6m) | 55lux(7m) | 48lux(9m) | 47lux(10m) | 40lux(12m) |
| Pole Distance | 25M | 35M | 40M | 45M | 50M |
| Installing Size | Φ61mm | Φ61mm | Φ61mm | Φ61mm | Φ61mm |
| Products Size | 520*380*120mm | 600*380*120mm | 720*380*120mm | 840*380*120mm | 960*380*120mm |
| Packing Size | 580*445*185mm | 660*445*185mm | 780*445*185mm | 900*445*185mm | 1020*445*185mm |
| Net Weight | 8KG | 10KG | 12KG | 14KG | 16KG |
| Gross Weight | 10KG | 12KG | 14KG | 16KG | 18KG |
Company:Zhejiang Coursertech Optoelectronics Co.,Ltd.,
Online inquiry website :https://www.led-solarstreetlights.com/
Website: www.courser-group.com
Contact Person : Nola Huang
E-mail: nolahuang@courser-group.com
Whatsapp:0086-15868323305
