16000lm Cool White Led Street Light 110 Watt 150w 120 Watt 220v 240V Road Light Lamp
Led Street Light Fast Response Speed, High Color Rendering Index
LED street lamps with directional light, low power consumption, good driving characteristics, fast response, high seismic capacity, long service life, green environmental protection and other advantages gradually into people's vision, the world has the most advantage of replacing the traditional light source of the new generation of energy-saving light source
The most important feature of lighting LED is that it has the function of directional light emission, because almost all power LED are equipped with reflectors, and the efficiency of this kind of reflector is obviously higher than that of lamps and lanterns.
In addition, the light efficiency test of LED already includes the efficiency of its own reflector.
The road lamps and lanterns using LED should make use of the directional emission characteristics of LED as far as possible, so that each LED in the road lamps and lanterns directly shoots light to each area of the illuminated road surface, and then uses the auxiliary light distribution of the lamp reflector to realize a very reasonable comprehensive light distribution of road lamps and lanterns.
In the design of the actual road lighting, under the premise of basically setting the firing direction of each LED, each LED is fixed on the lamp with a spherical universal joint. When the lamp is used in different height and irradiation width, the irradiation direction of each LED can be achieved satisfactory by adjusting the spherical universal joint
| Parameter Informations | JMJX-30 | JMJX-60 | JMJX-90 | JMJX-120 | JMJX-150 |
| Rated Power | 30W | 60W | 90W | 120W | 150W |
| LED Chip | 3W/pc | 3W/pc | 3W/pc | 3W/pc | 3W/pc |
| LED Quantity | 24 | 48 | 72 | 96 | 120 |
| Color Temperature | 4500-5500K | 4500-5500K | 4500-5500K | 4500-5500K | 4500-5500K |
| Input Voltage | AC100-260V | AC100-260V | AC100-260V | AC100-260V | AC100-260V |
| Frequency Range | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz |
| Power Factor | >0.97 | >0.97 | >0.97 | >0.97 | >0.97 |
| LED Luminous Efficiency | 140lm/w | 140lm/w | 140lm/w | 140lm/w | 140lm/w |
| (%) Lamp's Efficiency |
>92% | >92% | >92% | >92% | >92% |
| IP Grade | IP65 | IP65 | IP65 | IP65 | IP65 |
| Working life | >80000HRS | >80000HRS | >80000HRS | >80000HRS | >80000HRS |
| Environment Temperature | -30℃to+65℃ | -30℃to+65℃ | -30℃to+65℃ | -30℃to+65℃ | -30℃to+65℃ |
| Light Body material | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium |
| Pole Height | 6m | 7m | 9m | 10m | 12m |
| Central Illumination | 40lux(6m) | 55lux(7m) | 48lux(9m) | 47lux(10m) | 40lux(12m) |
| Pole Distance | 25M | 35M | 40M | 45M | 50M |
| Installing Size | Φ61mm | Φ61mm | Φ61mm | Φ61mm | Φ61mm |
| Products Size | 520*380*120mm | 600*380*120mm | 720*380*120mm | 840*380*120mm | 960*380*120mm |
| Packing Size | 580*445*185mm | 660*445*185mm | 780*445*185mm | 900*445*185mm | 1020*445*185mm |
| Net Weight | 8KG | 10KG | 12KG | 14KG | 16KG |
| Gross Weight | 10KG | 12KG | 14KG | 16KG | 18KG |
Zhejiang Coursertech Optoelectronics Co.,Ltd.,established in 1987,is a stock enterprise that professionally manufactures
illumination lights.The lights with "COURSER"brand have already enjoyed a certain reputation in both domestic and
international market.Coursertech has passed ISO 9001:2008,SGS,CCC,RoHS certificates etc.,meanwhile got 55 national
patents.
