ISO RoHS Yellow CBN Carbide Cutting Insert For Hardened Steel
VCGW110308 Coated CBN Carbide Turning Insert CBN Cutting Insert for hardened steel
Material:
Poly-Crystalline Diamond (PCD)
1. Reduce your tooling cost significantly
Polycrystalline cubic boron nitride(CBN)
1. With an excellent hot hardness
Description:
MANANOVA is the sub-brand of WORLDIA, positioned as a high-end standard series,
mainly promoting PCD / PCBN standard inserts.
MANANOVA takes “Easy choice and Fast delivery” as the feature, which intends to provide
fast and efficient service for domestic and foreign customers to meet their demand for standardized and universalized tools.
Application:
| MHN10C | Applied to the continuous cutting of hardened steel |
| MHN20C | Applied to medium interrupted cutting of hardened steel |
| MHN30C | Applied to the heavy interrupted cutting of hardened steel |
| MKN10 | Applied to the cutting of gray cast iron |
| MKN20 | Applied to the cutting of ductile iron |
| MSN10 | Applied to the cutting of powder metallurgy |
| MSN20 | Applied to the cutting of powder metallurgy |
Main products:
PCBN insert:
PCBN insert is suitable for machining of hardened steel, gray cast iron, ductile iron, and powder metallurgy.
PCD insert:
PCD insert is suitable for rough and finish machining of aluminum alloy and other non-metal materials.
Advantages:
· Universal
· Easy choice
· Fast delivery
Service:
· Online store service
· Local distributor support
· Technical support
Specification:
| Material | ISO H | ISO K | ISO S | ||||
| PCBN Grade | MHN10C | MHN20C | MNH30C | MKN10 | MKN20 | MSN10 | MSN20 |
| Smooth | Moderate | Toughness | Cast Iron | Ductile Iron | Powder Metallurgy | Powder Metallurgy | |
| Vc | 180(150~250) m/min |
100(50~150) m/min |
80(30~120) m/min |
600(300~800) m/min |
300(150~450) m/min |
300(200~500) m/min |
500(300~800) m/min |
| fn | 0.1(0.03~0.2) mm/r |
0.1(0.03~0.2) mm/r |
0.1(0.03~0.2) mm/r |
0.1(0.03~0.3) mm/r |
0.1(0.03~0.3) mm/r |
0.1(0.03~0.3) mm/r |
0.1(0.03~0.3) mm/r |
| % | 45~55 | 60~70 | 85~95 | 85~95 | 60~70 | 60~70 | 85~95 |
| Grain size | 1~2 um | 1~2 um | 2~3um | 2~3 um | 1~2 um | 1~2 um | 2~3 um |
| Bond | TiC | TiN | Co/W | Co/W | TiCN | TiCN | Co/W |
| VCGW | Shape | Dimensions | ||||||
| ANSI Code | ISO Code | Tips | IC mm |
S mm |
R mm |
Φd mm |
LE mm |
|
| All Stocked |
VCGW 221 | VCGW 110304 | 2N | 6.35 | 3.18 | 0.4 | 2.8 | 2.2 |
| VCGW 222 | VCGW 110308 | 2N | 6.35 | 3.18 | 0.8 | 2.8 | 2.2 | |
| VCGW 331 | VCGW 160404 | 2N | 9.525 | 4.76 | 0.4 | 4.4 | 2.2 | |
| VCGW 332 | VCGW 160408 | 2N | 9.525 | 4.76 | 0.8 | 4.4 | 2.2 | |
