50-60HZ Violet CTP Printing Machine Brand New / Sencond Hand
Price:
$13000-$23000
MOQ:
1
Delivery Time:
8 days
Brand:
PLATE-CD
Product Description
CTP plate making of machine ,CTP plate machine ,CTP offset machine ,offset ctp machine
Features:
- Applicable sheet model: 0.15 thickness -0.4 thickness.
- Resolution: 2,400dpi or 1,200dpi optional 2,540dpi or 1,270dpi (variable resolution option: the highest precision can reach 12,800dpi in the circumferential direction)
- Repeatability: ±0.01mm
- Output interface: optical fiber interface
- Environment: allowable temperature: 15-32℃, recommended temperature: 21-28℃, relative humidity: <70%
Product Description:
For plate making machines, our company has new and old machines. CTP machines and CTCP machines, split or conjoined. Choose different machines according to customer requirements.
A conventional computer plate-making machine requires a 50-square-meter room to place the machine. Keep the interior clean and tidy at all times.
| Technical Parameters | ||||||||||
| Model | Thermal | UV | ||||||||
| T824 | T832 | T848 | T864 | T8128 | U824 | U832 | U848 | U864 | U8128 | |
| NO.of lasers | 24 | 32 | 48 | 64 | 128 | 24 | 32 | 48 | 64 | 128 |
| Throughput(1130*800) | 13 | 18 | 23 | 28 | 45 | 13 | 18 | 23 | 28 | 45 |
| Max.Min.Format | MAX:1160*940 MIN:400*350 | MAX:1160*940 MIN:400*350 | ||||||||
| Laser source | 830nm | 405nm | ||||||||
| Resoiution | 2400DPI | |||||||||
| Loading system | Automatic,Semi-Auto(Optional Auto-loader) | |||||||||
| Plate requirement | CD. 0.15-0.4 (Thermal plate) | CD. 0.15-0.4 UV plate | ||||||||
| Interface | 1-bit Tiff interface and direct workflow driver,support CIP3/CIP4 | |||||||||
| Power | AC220V,50-60HZ 5.5KVA | |||||||||
| Work environment | Temperature:20-25℃,Humility:40%-80% |
|||||||||
