30w 70mm 24v DC Gear Motor 2000rpm With 5000 Hours Brush Life

Price Negotiable

Price: Negotiable

MOQ: 1 unit

Delivery Time: 3~7 working days for sample

Brand: CHE

Product Description

30w 70mm DC Gear Motor 24v 2000rpm

A brushless motor or BLDC gear motor is controlled by a motor driver or electronic controller that allows them to provide precise control of motor positioning, while delivering optimal speed and torque.
A brushless dc electric motor typically comes equipped with hall-effect sensors or an internal motor driver.
The accurate control of an ISL BLDC Motor results in reduced power consumption and less heat generation, creating a more efficient solution.
If you have any questions regarding the requirement of controllers to use, please contact us, our engineering team will provide a ull set of solution for you.
Available power 200w, 120w, 80w, 30w, 15w, available size 60mm, 70mm, 80mm, 90mm, 104mm

Motor Data:

Type

Voltage

Power

Rated Torque

No Load Speed

No Load Current

Rated Speed

Rated Current

Hall(Y.N)

Life(Hours)

Length

Internal Drive

Weight

N.m

r/min

F3B30--12GN-20S

0.143

2800

<0.9

2000

3.13

BOTH

>5000

YES

800

F3B30--24GN-20S

0.143

2800

<0.5

2000

1.56

BOTH

>5000

YES

800

F3B30--48GN-20S

0.143

2700

<0.25

2000

0.78

BOTH

>5000

yes

800

70 GearBox:

Gear Ratio	3	3.6	5	6	7.5	9	10	12.5	15	18	25	30	36	40	50	60	75	90	100	120	150	180	200
Output Speed (r/min)	667	556	400	333	267	222	320	160	133	111	80	67	56	50	40	33	27	22	20	17	13	11	10
Allowance Torque (N.m)	0.34	0.41	0.58	0.69	0.8	1.04	1.16	1.45	1.74	1.88	2.08	2.61	3.13	3.75	4.17	4.9	4.9	4.9	4.9	4.9	4.9	4.9	4.9
